Overview
- Description: Acts as a stabiliser when cabling is routed between bayed enclosures. With the PCP, plinths can be combined and fixed to the floor before the enclosures are mounted on them. The PCP can be used when cables have to go under the enclosure. For
- Material: 2 mm steel plate.
- Finish: RAL 7022 structured powder coating.
- Pack quantity: 2 profiles with mounting accessories.
- Comment: the reinforcement can be achieved with the used of plinth side panels in the joinings, but this solution is better because is joining the four corner pieces instead two and maintain the communication between the plinths
Specifications
Application | Controls and Drives; Factory Automation and Process Control |
Color | Umbra Gray |
Color Code | RAL 7022 |
Construction | 14 gauge |
Depth | 865 mm |
Depth | 34.06 in |
Finish | Powder Coated |
Height | 2.36 in |
Height | 60 mm |
Material | Mild Steel |
Mounting Type | Mounted at three heights on 200 mm high plinths |
Mounting Type | Mounted at three heights (top, middle, or bottom) |
Package Quantity | 2 |
Series | nVent PCP |
Size | 2.36 x 2.44 x 34.06 inch |
Size | 60x62x865mm |
Thickness | 2 mm |
Thickness | 14 ga |
Type | IEC Enclosure Accessories |
Weight | 6.7 lb |
Width | 62 mm |
Width | 2.44 IN |
Package Dimensions (L x W x H) | 1 IN x 1 IN x 1 IN |
Package Dimensions (L x W x H) | 2.54 cm x 2.54 cm x 2.54 cm |
Package Weight (Imperial) | 6.700 L |
Package Weight (Metric) | 3.039 kg |
