Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Mounts to the bottom of the enclosure
- 16-gauge (1.5 mm) steel construction with welded corners
- Seamless polyurethane gasket for water-tight and dust-tight seal
- Includes four M12 hex bolts for installation
- Compatible with casters or levelers for mobility or stability
Specifications
Application | Power Distribution; Controls and Drives |
Color | Light-Gray |
Color | Light Gray |
Color | RAL 7035 Light Gray |
Color Code | RAL 7035 |
Finish | Powder Coated |
Fits Frame | 400 x 600 mm |
IP Rating | IP55 |
Material | 16-gauge steel |
Material | Steel |
Material | Mild Steel |
Modification Services | Yes |
Mounting Type | Solid Base |
Mounting Type | Flush Mount |
Product Family | ProLine |
Series | nVent PB Series |
Series | ProLine G2 |
Size | fits 400x600mm |
Size | 400x600 mm |
Thickness | 16 ga |
Thickness | 1.52 mm |
Type | External Mounting for ProLine Industrial Enclosures |
Weight | 9.94 lb |
Package Dimensions (L x W x H) | 27.5 IN x 25.5 IN x 3 IN |
Package Dimensions (L x W x H) | 69.85 cm x 64.77 cm x 7.62 cm |
Package Weight (Imperial) | 9.940 L |
Package Weight (Metric) | 4.509 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the PB046 PROLINE® Solid Base
Installation guide for mounting the PB046 PROLINE® Solid Base.
Estimated time: 30m
Tools needed:
Drill, Level, Measuring tape, Pencil, Wrench
Supplies needed:
Mounting hardware (M12-1.75x20 screws), PB046 PROLINE® Solid Base
- Prepare the mounting location
Choose a suitable location for the PB046 PROLINE® Solid Base. Ensure the surface is level and can support the weight of the enclosure. Use a measuring tape and pencil to mark the mounting hole locations.
- Drill mounting holes
Drill the mounting holes at the marked locations. Ensure the drill bit size is appropriate for the M12-1.75x20 screws.
- Mount the solid base
Position the PB046 PROLINE® Solid Base over the drilled holes. Insert the M12-1.75x20 screws through the base and into the mounting surface. Use a wrench to tighten the screws securely, ensuring the base is level.
- Verify stability
Gently push and pull on the mounted PB046 PROLINE® Solid Base to ensure it is stable and securely fastened. Check that it remains level.
