nVent P2PSM105 - ProLine G2 Full Side-Mounting Subpanel, 1000x500, White
nVent

P2PSM105

UPC: 783510325381

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The nVent ProLine G2 Full Side-Mounting Subpanel (SKU: P2PSM105) is designed for efficient internal organization within modular enclosure systems. This white, 1000x500mm subpanel facilitates the mounting of electrical and electronic equipment. It features the patent-pending EZ-Load Mounting System, offering versatile installation options including vertical front, rear, side loading, and a controlled horizontal loading method. This adaptability ensures reduced installation time and enhanced safety. Constructed by nVent, this subpanel is built for durability in industrial settings. Its side-mounting design maximizes usable enclosure space and aids cable management. The ProLine G2 series integrates seamlessly with nVent ProLine G2 modular enclosures, providing a comprehensive solution for control panels, power distribution, automation, and telecommunications equipment. The white finish provides a clean aesthetic and aids visual inspection. Key specifications include dimensions of 1000mm height and 500mm width, with a 12 gauge (2.5mm) mild steel construction. It is suitable for applications requiring secure and efficient internal component organization in manufacturing, process control, utilities, and data centers.
  • 1000x500mm white full side-mounting subpanel
  • Features nVent's patent-pending EZ-Load Mounting System
  • Offers versatile loading: vertical (front, rear, side) and horizontal
  • Maximizes enclosure space and improves cable management
  • Durable 12 gauge (2.5mm) mild steel construction
  • Side-mount panels must be used for the sides of the enclosure; they can be installed on the interior sides of frames
  • Optional panel support bracket available for applications requiring more support in the center of the subpanel; this is required if the enclosure will be tipped in transit or if the panel is not located at the bottom of the enclosure on the glide blocks
  • Panels can be installed in the rearmost position, or positioned so joined enclosures provide a continuous mounting surface without requiring joining panels
  • High space efficiency ratio (HxW of subpanel)/(HxW of frame) of 84 percent
  • Side-mount panels must be used for the sides of the enclosure; they can be installed on the interior sides of frames

Specifications

Application
Controls and Drives; Power Distribution
Color
White
Finish
Powder Coated
Fits Frame
1000x500 mm
Material
Mild Steel
Mounting Type
Side-Mount
Mounting Type
Side-Mounting
Product Family
ProLine
Series
ProLine G2
Size
1000x500 mm
Size
1000x500
Thickness
12 ga
Thickness
2.66 mm
Type
Side Mount
Weight
28.8 lb
Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum

14A0705

Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum
Eclipse Inner Panel - Fits Encl. 30 x 30 - Steel/Wht

EP3030

Eclipse Inner Panel - Fits Encl. 30 x 30 - Steel/Wht
