Overview
- UL 508A listed, NEMA Type 12, CSA certified for industrial safety compliance
- Pre-configured package includes frame, solid door with handle/lock, top, rear cover, mounting subpanel, gland plate, and lifting eyes
- 600x600x600mm dimensions with 528x528mm max subpanel for flexible component mounting
- Solid steel construction with light gray finish for durability and visibility
- Compatible with side covers for baying applications and future system expansion
- Single/primary door includes Smooth Glide Latching System, 3-point roller latch system with timed latch engagement, for enclosures greater than or equal to 1000 mm in height; system ensures a solid and repeatable seal with a low closure force
- 2-door enclosures include overlapping double doors to provide full-width open front, with a secondary door that latches with two levers
- Reversible hinging on single doors (default left hinge), and on overlapping double doors (default right door primary door)
- Two grounding studs present on each door
- Low-Profile Flush Swing Handle with key lock on standard versions; double bit lock on 'E' versions; other handle options available (sold separately)
Specifications
Application | Power Distribution; Controls and Drives |
Color | Light Gray |
Color Code | RAL 7035 |
Depth | 23.62 |
Depth | 605 |
Door Quantity | 1 |
Finish | Powder Coated |
Height | 23.7 |
Height | 602 |
Material | Mild Steel |
Max Rack Mount Unit | 8 |
Max Subpanel Size | 19.9 x 20.8 in |
Product Family | ProLine |
Type | Mild Steel Modular Industrial Enclosures |
Width | 23.92 |
Width | 608 |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
Frequently Asked Questions
What frame sizes are available for ProLine G2?
Frame heights range from 600 mm to 2200 mm, with various widths and depths.
What materials are used in the ProLine G2 frame?
The frame is made of 12 gauge (2.5 mm) roll-formed steel.
How can I contact nVent for configuration help?
You can contact nVent via email at [email protected] or call 763 422 2211.
What is the load rating of the ProLine G2 frame?
The ProLine G2 frame has a 15% higher load rating than the competition.
What type ratings are available for the ProLine G2?
The ProLine G2 is available in Type 12 and Type 3R ratings.
What safety features are included with the ProLine G2?
Safety features include mechanical and electrical interlocks, disconnect doors, and barrier panels.
What options are available for cable management?
Cable management solutions include cable entry cabinets, tie-down brackets, and D-Ring cable managers.
What is the maximum weight capacity of the subpanel?
The subpanel can hold greater than 45% more weight than previous models.
What is the weight capacity of the mobile base?
The mobile base has a load-bearing capacity of 1000 lb (453.6 kg).
What are the EMC options for the ProLine G2?
EMC options are available for various components including frames, covers, and tops.
