Contact for Pricing
Overview
- Straps mount to the door bar
- Load rating: 100 lbs. (45.4 kg)
- 16 gauge (1.5 mm), mild steel
- Facilitates vertical positioning of accessories
- Plated finish provides corrosion resistance
Specifications
Application | Power Distribution; Controls and Drives |
Color | Unpainted |
Depth | 0.72 |
Depth | 18 |
Finish | Plated |
Fits Frame Width | 600 mm |
Height | 0.86 |
Height | 22 |
Material | Mild Steel |
Material | Plated Steel |
Mounting Type | Door Mounting |
Product Family | ProLine |
Series | ProLine G2 |
Size | 600mm (20.0 inch) |
Thickness | 1.52 mm |
Thickness | 16 ga |
Type | External Mounting for ProLine Industrial Enclosures |
Weight | 1.76 lb |
Width | 20 |
Width | 508 |
Package Dimensions (L x W x H) | 29.5 IN x 5.5 IN x 5 IN |
Package Dimensions (L x W x H) | 74.93 cm x 13.97 cm x 12.7 cm |
Package Weight (Imperial) | 1.760 L |
Package Weight (Metric) | 0.798 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
Frequently Asked Questions
What material are the nVent ProLine G2 Door Bar Grid Straps made of?
The nVent ProLine G2 Door Bar Grid Straps are made of 16-gauge plated steel.
What is the length of the nVent ProLine G2 Door Bar Grid Straps?
The nVent ProLine G2 Door Bar Grid Straps are 600mm in length.
What system are these grid straps a part of?
These grid straps are a component of the nVent ProLine G2 Grid Mounting System.
What is the benefit of the plated finish on these straps?
The plated finish enhances corrosion resistance, extending the lifespan of the straps in demanding industrial environments.
What frame width are these 600mm straps optimized for?
The 600mm length straps are optimized for 600mm frame width enclosures.
