Contact for Pricing
Overview
- Smooth Glide latching system – for a smooth, reliable and repeatable door close over enclosure lifetime
- Low-profile Swing Handle with key lock; other options available
- Seamless polyurethane gasket (UL Component Recognized) provides a water-tight, dust-tight seal against moisture and contaminants
- Single doors available for frames up to 1000 mm wide
- Overlapping double doors available for frames 800 mm wide and greater
- Door bar system on all doors
- Timed latch engagement to ensure top and bottom of door catch reliably
- Durable, double-flanged latch rod and three Delrin® rollers to prevent metal-on-metal grinding
- 3-point latch system for doors ≥ 1000 mm in height
- Key lock handle standard; other options available
Specifications
Application | Power Distribution; Controls and Drives |
Color | Light Gray |
Color Code | RAL 7035 |
Door Quantity | 1 |
Finish | Galvanized |
Fits Frame | 2200x600 mm |
IP Rating | IP55 |
Material | 14-gauge steel |
Material | Mild Steel |
Nema Rating | Type 12 |
Product Family | ProLine |
Series | ProLine G2 |
Size | 2200x600mm |
Specialty | EMC Components |
Thickness | 1.9 mm |
Thickness | 14 ga |
Type | External Mounting for ProLine Industrial Enclosures |
Weight | 56 lb |
