Overview
- Used to provide best load distribution while lifting two or three joined/ganged enclosures with up to 1000 lbs (453 kg) of equipment and cabling in each bay
- Angles mount to top of enclosure frame corner blocks and do not require removal of top cover for installation.
- Kit consists of two angles, four hex cap screws and four washers.
- Lifting Angles are designed for overhead lifting in conjunction with shackles and a spreader bar. Use of shackles instead of hooks is preferred. The angle between the top of the enclosure and the cable or chain must be at least 45°. Use only slings and sp
- The angle between the top of the enclosure and the cable or chain must be at least 45 degrees
- Lifting Angles are designed for overhead lifting in conjunction with shackles and a spreader bar
- Use of shackles instead of hooks is preferred
- 10 gauge (3.0mm), mild steel
Specifications
Application | Power Distribution; Controls and Drives |
Color | Unpainted |
Depth | 2 |
Depth | 51 |
Finish | Plated |
Height | 2.99 |
Height | 76 |
Material | Mild Steel |
Product Family | ProLine |
Thickness | 10 ga |
Thickness | 3.4 mm |
Type | External Mounting for ProLine Industrial Enclosures |
Weight | 3 lb |
Width | 4.25 |
Width | 108 |
Package Dimensions (L x W x H) | 11.5 IN x 9.5 IN x 2.5 IN |
Package Dimensions (L x W x H) | 29.21 cm x 24.13 cm x 6.35 cm |
Package Weight (Imperial) | 3.000 L |
Package Weight (Metric) | 1.361 kg |
