Overview
- 19-inch rack mounted, securing to the front surface of rack angles (sold separately); mounting hardware supplied
- Integral box contains the drawer and protects surrounding internal equipment
- Drawer extends 13 inches (330 mm) on ball bearing slides
- Front includes handle and key lock
- Includes front handle and key lock for security; mounting hardware included
Specifications
Application | Controls and Drives |
Color | Light Gray |
Color Code | RAL 7035 |
Finish | Powder Coated |
Fits Rack Width | 19 in. in |
Material | Mild Steel |
Material | Steel |
Modification Services | Yes |
Mounting Type | Rack-Angle Mounted |
Product Family | ProLine |
Rack Units | 3 |
Size | 19-inch 3U |
Size | 3Ux19.00 in |
Thickness | 1.52 mm |
Thickness | 16 ga |
Type | Networking Accessories |
Weight | 22.8 lb |
Package Dimensions (L x W x H) | 20 IN x 20 IN x 7.87 IN |
Package Dimensions (L x W x H) | 50.8 cm x 50.8 cm x 19.9898 cm |
Package Weight (Imperial) | 22.800 L |
Package Weight (Metric) | 10.342 kg |
