nVent MCD20128PERDR5 - Modular Double Door, MCD no Plate, 2000x1200x800mm, Rear Door, IP55, Mild Steel
nVent

MCD20128PERDR5

UPC: 783510492052

Contact for Pricing

Overview

The **nVent MCD20128PERDR5** modular double-door enclosure delivers exceptional space efficiency and robust protection for critical electrical and electronic components in demanding industrial environments. Designed by **nVent**, a global leader in thermal management and electrical enclosures, this **2000x1200x800mm** floor-standing unit features a **rear-opening door** and **IP55-rated protection**, ensuring reliable safeguarding against dust ingress and water jets while optimizing installation flexibility in confined spaces. Unlike single-door enclosures, the **split-door design** distributes load capacity evenly, reducing stress on hinges and improving operational longevity—ideal for high-traffic or high-value applications where equipment accessibility and durability are paramount. Engineered for **modular expandability**, the MCD series allows seamless integration with additional enclosures, enabling scalable solutions for growing infrastructure needs. The **mild steel construction** provides a cost-effective balance of strength and corrosion resistance, while the **no-plate design** simplifies cable entry and customization. With a **rear door configuration**, this enclosure maximizes front-of-rack space—a critical advantage in data centers, telecom facilities, and industrial control rooms where floor space is at a premium. **Key Applications & Industries:** The MCD20128PERDR5 excels in environments requiring **high ingress protection (IP55)** and **space-conscious design**, including: - **Industrial automation** (PLCs, motor drives, and control panels) - **Renewable energy** (inverter enclosures, battery management systems) - **Telecommunications** (network cabinets, fiber optic distribution hubs) - **Commercial buildings** (HVAC controls, security systems) - **Oil & gas** (remote monitoring stations, hazardous-area-rated variants) **Why Choose nVent MCD Series?** nVent’s **MCD range** is trusted by engineers and facility managers worldwide for its **modularity, durability, and compliance** with international standards (e.g., IEC 62208, UL 50E). The **IP55 rating** ensures protection against environmental contaminants, while the **split-door design** enhances serviceability by allowing independent access to either side of the enclosure without disrupting adjacent equipment. Installation is streamlined with **pre-drilled mounting holes** and **compatible accessories** (e.g., cable glands, ventilation panels), reducing downtime during deployment. **Selection & Installation Considerations:** When specifying the MCD20128PERDR5, professionals prioritize: - **Load-bearing capacity** (distributed across two doors for heavier components) - **Thermal management** (options for fan trays or heat exchangers in high-power applications) - **Future scalability** (modular expansion without replacing the entire enclosure) - **Compliance** (NEMA 4X equivalent for outdoor or corrosive environments) For optimal performance, ensure proper **grounding, cable management, and airflow** during installation. The **rear-door design** simplifies back-of-rack access, but verify clearance requirements for rear-mounted equipment. nVent provides **detailed technical documentation**, including CAD models and installation guides, to support seamless integration into existing systems. **Manufacturer Trust & Support:** As a **US-manufactured** product from nVent (NYSE: NVT), the MCD20128PERDR5 benefits from **global supply chain reliability**, **rigorous quality control**, and **dedicated technical support**. nVent’s legacy in thermal management and electrical protection—spanning over a century—underscores its commitment to innovation and customer success. Whether for **new construction, retrofits, or upgrades**, the MCD series delivers a **future-proof solution** that balances performance, cost, and compliance.
  • Material: Frame: 1.5 mm painted steel. Doors: 2 mm painted steel. Rear, roof and side panels: 1.5 mm painted steel. Mounting plate: 3 mm galvanized steel. Bottom plates: 1 mm galvanized steel.
  • Frame: Seam welded reversed open profiles with 25 mm hole pattern, according to DIN 43660. Including integrated external hole pattern.
  • Doors: Mounted with four hinges. Including door frame with 25 mm hole pattern. Doors cannot be reversed. Separate doors to be ordered for left hand door locking.
  • Rear panel: Fitted by M6 torx screws. Standard facilities for rear doors mounting. Split rear panels in 1600 mm wide enclosures. RD version comes with rear door instead of rear panel.
  • Side panels: Supplied as an accessory.
  • Roof panel: Removable.
  • Lock: Espagnolette 4-point locking system in the main door and 2-point locking system in the slave door. Standard double-bit lock with 3 mm insert. Standard inserts, cylinders, lift handles and T-handles are available as accessories.
  • Bottom plates: Consists of three or four (D>600) pieces.
  • Mounting plate: Double folded and slides into position. Adjustable in depth by steps of 25 mm, with the MPD02 accessory. Supplied, attached on the outside of the enclosure packaging.
  • Earthing: All panels are earthed through their fittings and equipped with a separate earthing stud.

Specifications

Package Dimensions (L x W x H)
79.12 IN x 8.25 IN x 8.5 IN
Package Dimensions (L x W x H)
200.9648 cm x 20.955 cm x 21.59 cm
Package Weight (Imperial)
410.400 L
Package Weight (Metric)
186.157 kg
