Contact for Pricing
Overview
- MaxRack Air baffle and Vertical Cable Manager accessory kits ensure CISCO switch compliance
- They provide the required cold air access and provisions for high-density cabling
- Baffles and cable manager uprights made of aluminum; supporting fingers made of composite
- Cisco developer registered
- Dimensions: 84.13 x 12.00 x 23.68 in (2137 x 305 x 601 mm)
Specifications
Application | Networking, Storage and Data Center |
Color | Jet Black |
Color | Black |
Color Code | RAL 9005 |
Depth | 601 mm |
Depth | 23.68 |
Depth | 601 |
Finish | Powder Coated |
Finish | Black;Powder Coating |
Height | 84.13 |
Height | 2,137 |
Height | 2,137 mm |
Material | Aluminum, Composite |
Material | Aluminum |
Modification Services | No |
Mounting Type | Rackmount |
Product Family | MaxRack |
Series | MaxRack |
Size | 84.13x12.00x23.68 in (2137x305x601 mm) |
Thickness | 14 |
Thickness | 1.63 |
Thickness | 1.63 mm |
Type | Open Frame Racks |
Use With Cisco Switch | Catalyst 6509/6513 |
Use With MaxRack | M8416B45 |
Weight | 110 lb |
Width | 12 |
Width | 305 |
Width | 305 mm |
Works With | Catalyst 6509 |
Package Dimensions (L x W x H) | 87 IN x 12 IN x 14.5 IN |
Package Dimensions (L x W x H) | 220.98 cm x 30.48 cm x 36.83 cm |
Package Weight (Imperial) | 110.000 L |
Package Weight (Metric) | 49.896 kg |
