Overview
- Includes mounting hardware for window and optional front plate
- Window kit is hinged on left side with a 140-degree door opening and a quarter-turn slotted latch
- Purchase Front Plate separately
- Hinged design for easy and safe access to HMI and components
- Designed for 250x250mm enclosure openings, compatible with HOFFMAN enclosures
Specifications
Accepts Front Plate | LFP2525 |
Application | Controls and Drives |
Color | Unpainted |
Color | Black |
Depth | 42 mm |
Depth | 1.64 |
Depth | 42 |
Finish | Smooth Matte |
Height | 250 mm |
Height | 9.84 |
Height | 250 |
Material | Polycarbonate |
Modification Services | Yes |
Mounting Type | Hinged |
Product Family | InLine |
Series | InLine HMI |
Size | fits 250x250mm |
Size | 250x250 mm |
Thickness | 0.12 in |
Thickness | 3 mm |
Type | HMI Enclosure Systems |
Type | Other Accessories |
Weight | 2.6 lb |
Width | 9.84 |
Width | 250 |
Width | 250 mm |
Window Size | 8.78 x 7.97 in |
Window Size | 223 x 202 mm |
Works With | NEMA |
Package Dimensions (L x W x H) | 10.3 IN x 10.2 IN x 3.6 IN |
Package Dimensions (L x W x H) | 26.162 cm x 25.908 cm x 9.144 cm |
Package Weight (Imperial) | 2.600 L |
Package Weight (Metric) | 1.179 kg |
