Contact for Pricing
Overview
- Key is included
- High-strength steel with textured black finish for durability and corrosion resistance
- Direct replacement for standard slotted quarter-turn latches in nVent LLH/LHC systems
- Compatible with key numbers 333, 1333, EK333, and GX130
- Ideal for manufacturing, warehousing, commercial buildings, and HVAC systems
Specifications
Application | Controls and Drives |
Color | Black |
Finish | Textured |
Material | Mild Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Product Family | InLine |
Type | Industrial Door Mounting and Locks |
Weight | 0.14 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 7.25 IN x 5 IN x 0.5 IN |
Package Dimensions (L x W x H) | 18.415 cm x 12.7 cm x 1.27 cm |
Package Weight (Imperial) | 0.140 L |
Package Weight (Metric) | 0.064 kg |
