Overview
- Seams continuously welded and ground smooth
- External formed body flange channels away liquids
- Large perimeter body opening
- Mounting holes in back of body for direct mounting or optional external mounting brackets
- Bonding provision on cover and body
- Metalized non-woven fabric EMI/RFI material covering UL94HP-rated urethane foam gasket
- Plated interior surfaces for gasket contact areas and conduit entries
- Hardware kit includes panel mounting screws, grounding hardware and sealing washers for wall-mounting holes
- Installation instructions
- Shielding effectiveness greater than 50 dB at 1 GHz
Specifications
Application | Controls and Drives |
Color | Light Gray |
Color | Gray;LtGray |
Color Code | RAL 7035 |
Conductive Steel Panel | LP3530G |
Depth | 200 mm |
Depth | 7.87 |
Depth | 200 |
Finish | Powder Coated |
Height | 13.78 |
Height | 350 |
Height | 350 mm |
IP Rating | IP54 |
Material | Mild Steel |
Material | Steel |
Modification Services | Yes |
Mounting | Wall Mounting Brackets Available |
Mounting | 13.07 x 9.25 in |
NEMA Rating | 1 Indoor, electrical protection |
NEMA Rating | Type 1 |
NEMA Rating | 1 |
Panel Size | 13.03 x 11.06 in |
Panel Size | 331 x 281 mm |
Product Family | InLine |
Protection Rating | NEMA Type 1 |
Series | InLine EMC |
Size | 350x300x200mm |
Steel Panel | LP3530 |
Thickness | 1.5 mm |
Thickness | 16 ga |
Thickness | 51.40mm (2.024") |
Type | Mild Steel Wall Mounted Industrial Enclosures |
Type Number | Type 12 |
Weight | 13.4 lb |
Width | 11.81 in |
Width | 300 mm |
Package Dimensions (L x W x H) | 14.6 IN x 12.7 IN x 8.9 IN |
Package Dimensions (L x W x H) | 37.084 cm x 32.258 cm x 22.606 cm |
Package Weight (Imperial) | 13.400 L |
Package Weight (Metric) | 6.078 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the LHC353020EMC Controller
This guide provides step-by-step instructions for installing and configuring the LHC353020EMC Controller.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the LHC353020EMC controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the power supply
Using terminal connectors, connect the power supply wires to the designated input terminals on the controller. Ensure correct polarity to avoid damage.
- Verify connections
Use a multimeter to check the voltage at the input terminals to ensure proper power supply before powering on the controller.
- Configure initial settings
Power on the controller and access the configuration menu. Set the required parameters according to your application needs.
- Calibrate the controller
Follow the calibration procedure outlined in the user manual to ensure accurate readings and functionality.
