Contact for Pricing
Overview
- The AccessPlus Cable Managers provide cable routing and support inside the AccessPlus cabinets
- They're used when ordering additional rack angles for 28-inch wide cabinet
- Features a latching hinged door for easy access and concealment of wiring.
- Includes movable plastic spools for precise cable organization and management.
- Supports substantial cable loads with a 350 lbs load rating for the 48-inch height.
Specifications
Application | Networking, Storage and Data Center |
Color | Jet Black |
Color | Black |
Color Code | RAL 9005 |
Finish | Powder Coated |
Finish | Black;Powder Coating |
Fits Cabinet | A = 48.00; B = 28.00 in |
Fits Height | 48 in |
Fits Width | 28 in |
Material | Mild Steel |
Material | Steel (14 and 16-gauge) |
Material | Mild Steel;Steel |
Modification Services | Yes |
Product Family | AccessPlus |
Series | nVent AccessPlus |
Size | 48 inches tall |
Thickness | 1.9 mm |
Thickness | 14 |
Thickness | 1.9 |
Type | Networking Accessories |
Weight | 12.5 lb |
Package Dimensions (L x W x H) | 45.75 IN x 10.5 IN x 5 IN |
Package Dimensions (L x W x H) | 116.205 cm x 26.67 cm x 12.7 cm |
Package Weight (Imperial) | 12.500 L |
Package Weight (Metric) | 5.670 kg |
