Contact for Pricing
Overview
- Vertically oriented 19-inch equipment mounting creates a compact, wind-resistant cabinet
- Integral solar shield reduces solar heat load
- Right-side, solid gland plate can be removed and modified as needed
- 6 RU Rack has square hole spacing per EIA universal standards; order cage nuts separately
- Quarter-turn, multi-point, vault-style latching system increases protection and security
- 160-degree door opening with quick-release, retained hinge pins
- Body and door ground studs for bonding and grounding
- Foam-in-place seamless gasket for superior protection against dust and liquid ingress
- Back is prepared with mounting provisions for standard panels
- Mounts to poles or walls
Specifications
Application | Datacom and Telecom Equipment |
Color | Light Gray |
Color | Lt Gray |
Color | Gray |
Color | Grey |
Color Code | RAL 7035 |
Depth | 9 mm |
Depth | 0.35 |
Depth | 9 |
Finish | Powder Coated |
Finish | Lt Gray;Powder Coating |
Height | 590 mm |
Height | 23.23 |
Height | 590 |
Ip Rating | IP66/IP67 |
Material | Aluminum |
Modification Services | No |
Mounting Type | Vertical Mount, Pole-Mount |
Mounting Type | Vertical Mount |
Nema Rating | Type 3, 3R, 4, 4X, 12 |
Product Family | ComLine |
Series | COMLINE |
Size | 23.23x12.68x0.35 |
Size | 23.23x12.68x0.35 inches |
Thickness | 0.1 |
Thickness | 2.5 |
Thickness | 2.5 mm |
Type | Data Networking Freestanding Cabinets |
Use With | T20 AC Unit |
Weight | 3 lb |
Width | 12.68 |
Width | 322 |
Width | 322 mm |
Package Dimensions (L x W x H) | 24 IN x 13.5 IN x 1.5 IN |
Package Dimensions (L x W x H) | 60.96 cm x 34.29 cm x 3.81 cm |
Package Weight (Imperial) | 3.000 L |
Package Weight (Metric) | 1.361 kg |
