nVent EDR19FM51U6 - Open Frame Rack 2-Post, 96.00x20.28x18.00, Black, Aluminum
nVent

EDR19FM51U6

UPC: 783510253257

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The nVent EDR19FM51U6 is a robust 2-post open frame rack engineered for critical infrastructure deployment in communication data centers and telecommunication rooms. This 8-foot (96.00 inches) tall rack provides a substantial 51 rack units (U) of vertical mounting space, ideal for high-density equipment installations. Its 19-inch EIA standard width ensures compatibility with a vast array of network, server, and audio-visual equipment. Constructed from high-quality aluminum, this open frame rack offers a compelling balance of strength and lightweight design, facilitating easier handling and installation. The sleek black finish not only provides a professional aesthetic but also offers a degree of surface protection. The 18.00-inch depth is optimized for standard networking and telecommunications equipment, while the 20.28-inch overall width ensures stability without consuming excessive floor space. This particular model features a 6-inch column width, offering a sturdy foundation for your equipment. Designed with fundamental functional requirements in mind, the nVent 2-post open frame rack excels at structuring and organizing cables, a critical aspect of maintaining efficient and reliable network operations. Proper cable management within an open frame rack is paramount for airflow, accessibility, and preventing signal interference. Professionals often select open frame racks for their cost-effectiveness and ease of access, making them a popular choice for environments where equipment visibility and rapid maintenance are key priorities. Key features and benefits of the nVent EDR19FM51U6 include: * **Generous Mounting Space:** 51U of vertical space accommodates a significant amount of equipment. * **Standard 19-inch EIA Width:** Ensures broad compatibility with industry-standard rack-mount devices. * **Durable Aluminum Construction:** Offers excellent strength-to-weight ratio for ease of installation and long-term reliability. * **Optimized Depth:** 18.00 inches deep, suitable for most networking and telecom gear. * **Stable 6-inch Column Width:** Provides a solid and secure mounting platform. * **Open Frame Design:** Facilitates superior airflow and easy access for maintenance and cable management. * **Professional Black Finish:** Enhances aesthetics and offers surface protection. This rack is manufactured in the USA, underscoring nVent's commitment to quality and domestic production. nVent is a globally recognized leader in electrical, thermal management, and enclosure solutions, known for delivering innovative and reliable products that protect critical infrastructure. When deploying essential network components, choosing an open frame rack from a trusted manufacturer like nVent ensures that your equipment is housed securely and efficiently, contributing to the overall performance and longevity of your IT and telecommunications infrastructure. The UNSPSC code 43223308 further categorizes this product within the broader market of racks and cabinets.
  • Range of heights from 4 feet to 9 feet (24U to 58U) to match capacity requirements; 19-inch Rack Packages are 7-feet high
  • Side rails are tapped on both sides with 12-24UNC threads for quick installation
  • EIA Universal 5/8 inch - 5/8 inch - 1/2 inch vertical mounting hole pattern matches industry standards
  • RU markings on both front and back of uprights make it easier to mount equipment
  • Packed unassembled in individual cartons; assembly hardware is furnished for convenient storage and installation
  • Convenient rack and cable manager packages offered with either one or two 6-inch cable managers; includes one-piece hinged cover
  • Convenient rack and cable manager packages offered with either one or two 6-in. cable managers; includes one-piece hinged cover

Specifications

Application
Networking, Storage and Data Center
Color
Jet Black
Color
Black
Color Code
RAL 9005
Depth
18
Depth
457
Depth
457 mm
Finish
Powder Coated
Height
96
Height
2,438
Height
2,438 mm
Material
Aluminum
Modification Services
Yes
Mounting Type
2-Post Open Frame
Nominal Frame Height
8 ft. ft
Rack Units
51
Series
EDR Series
Size
96.00x20.28x18.00 in
Thickness
3.5 mm
Thickness
0.14
Thickness
3.5
Type
Open Frame Racks
Weight
33 lb
Width
20.28
Width
515
Width
515 mm
Package Dimensions (L x W x H)
97.25 IN x 7 IN x 4.5 IN
Package Dimensions (L x W x H)
247.015 cm x 17.78 cm x 11.43 cm
Package Weight (Imperial)
33.000 L
Package Weight (Metric)
14.969 kg
