Contact for Pricing
Overview
- Universal mounting pattern for 2- and 4-post open-frame racks
- Easy-to-install with self-aligning, self-captivating carriage bolts for single-sided attachment
- Arrowhead supporting fingers provide easy insertion, removal and alignment of Cat 5e, 6, 6A and other cable types
- Deep cable depth provides smooth transition of cables from vertical to horizontal positions
- Large feed-through holes and pre-scored grommets provide cable feed from front to back of cable manager
- Unobstructed cable access for all rack unit locations
- Extra deep cable channel for maximum cable density has multiple cable tie-down points
- Standard front cover, with field installed snap hinges, provides cable access from right, left or neutral
- Double-sided models with supporting fingers include front central latching cover and rear snap-on cover
- Double-sided models with posts and gates support and contain cables. Five posts and gates are included; additional sets are available as accessories
Specifications
Application | Networking, Storage and Data Center |
Color | Black |
Color | Jet Black |
Color Code | RAL 9005 |
Depth | 20.85 in |
Finish | Powder Coated |
Height | 7 in |
Material | Steel |
Material | Mild Steel |
Modification Services | Yes |
Mounting Type | Open-frame rack mounting (2- and 4-post) |
Mounting Type | Vertical |
Product Family | CableTek |
Rack Units | 45 |
Series | CableTek-EC |
Size | 84.00x6.50x20.85 |
Size | 84.00x6.50x20.85 inches |
Thickness | 1.9 mm |
Thickness | 14 |
Thickness | 1.9 |
Type | Rack and Cabinet Cable Management |
Weight | 70 lb |
Width | 6 IN |
Package Dimensions (L x W x H) | 87.5 IN x 20 IN x 8.5 IN |
Package Dimensions (L x W x H) | 222.25 cm x 50.8 cm x 21.59 cm |
Package Weight (Imperial) | 70.000 L |
Package Weight (Metric) | 31.752 kg |
