nVent DV12DF7 - CableTek Vertical Cable Manager Double Fingers, 84.00x13.25x21.20, Black, Alum
nVent

DV12DF7

UPC: 783510262860

Documents & Media
Installation Instructions

Contact for Pricing

Overview

Optimize your data center and network infrastructure with the nVent CableTek Vertical Cable Manager, SKU DV12DF7. Engineered by nVent, a trusted leader in electrical and electronic solutions, this robust vertical cable manager offers superior organization and protection for your critical cabling. The DV12DF7 model features a double-finger design, providing exceptional support and management capabilities for a wide range of network cables. Its substantial dimensions of 84.00 inches in height, 13.25 inches in width, and 21.20 inches in depth ensure ample space for high-density cabling environments. Constructed from durable black aluminum, this manager is built to withstand the rigors of industrial and commercial installations. This vertical cable manager is designed for versatile mounting, easily attaching to the sides of or between standard 2-post and 4-post open frame racks. This flexibility allows for seamless integration into existing or new rack configurations, maximizing space utilization and improving accessibility. The front of the manager is specifically designed to expertly handle and support patch cords, ensuring they remain neatly organized and protected from damage. This organization is crucial for maintaining network performance and reducing troubleshooting time. Beyond patch cord management, the rear section of the nVent CableTek Vertical Cable Manager is adept at supporting and organizing higher-category cables, including Cat 5e, Cat 6, Cat 6A, and fiber optic cables. This comprehensive management system prevents cable strain, reduces signal interference, and enhances airflow within the rack, contributing to the overall health and longevity of your network equipment. Proper cable management is a cornerstone of reliable IT infrastructure, and the DV12DF7 delivers on this essential requirement. Key features and benefits include: * **High Capacity Management:** Accommodates a significant volume of patch cords and backbone cabling. * **Dual-Sided Functionality:** Dedicated sections for patch cords (front) and higher-category/fiber optic cables (rear). * **Versatile Mounting Options:** Installs on the sides or between 2- and 4-post open frame racks. * **Durable Construction:** Made from black aluminum for long-lasting performance and a professional aesthetic. * **Enhanced Airflow:** Promotes better cooling within the rack by preventing cable congestion. * **Reduced Downtime:** Simplifies maintenance and troubleshooting by keeping cables organized and accessible. Manufactured in the United States, the nVent CableTek Vertical Cable Manager DV12DF7 (UNSPSC Code: 43223308) represents a commitment to quality and performance. Invest in superior cable management to ensure the reliability, scalability, and efficiency of your network infrastructure. This solution is ideal for data centers, telecommunications rooms, enterprise networks, and any environment where organized and protected cabling is paramount.
  • Easily removable one-piece front cover with access from right or left as needed opens 180º to allow full access to cables
  • Self-aligning bolt locations minimize lifting and speed installation
  • Self-captivating fasteners; bolt doesn't turn while tightening nut
  • Generous finger depth allows for maximum cable density and allows smooth transitions from vertical to horizontal positions
  • Unobstructed cable access to rack equipment - no keep-out areas
  • Rounded edges on composite material and grommets protect cable jackets from damage
  • Robust arrowhead fingers are shaped to funnel cables into base and are made of composite material
  • Cable tie-down points provided on back
  • Pass-through holes protect cable while facilitating routing between front and back
  • Single central door latch allows quick and easy access to cables

Specifications

Application
Networking, Storage and Data Center
Color
Jet Black
Color Code
RAL 9005
Depth
21.2 in
Finish
Powder Coated
Fits Rack Height
7 ft
Material
Aluminum
Modification Services
Yes
Product Family
CableTek
Rack Units
45
Thickness
2 mm
Thickness
0.08
Thickness
2
Type
Rack and Cabinet Cable Management
Weight
64 lb
Package Dimensions (L x W x H)
86.25 IN x 27.5 IN x 16 IN
Package Dimensions (L x W x H)
219.075 cm x 69.85 cm x 40.64 cm
Package Weight (Imperial)
64.000 L
Package Weight (Metric)
29.030 kg
