Contact for Pricing
Overview
- Plastic mounting foot kits are rated for 500 lb (227 kg) maximum load
- Sealing washers are provided with each kit to maintain Type 4 and 12 after installation
- Stainless steel and plastic mounting bracket kits are rated to Type 4X
- All hardware is included
- Corrosion-resistant plated steel construction for harsh industrial environments
Specifications
Accessory Type | Mounting Accessories |
Application | Controls and Drives |
Color | Unpainted |
Depth | 0.07 in |
Depth | 2 mm |
Fastener Thread Size | #10-32 |
Finish | Plated |
Height | 1.5 IN |
Height | 44 IN |
L | 8.75 in |
L | 2 in |
Material | Plated Steel |
Material | Mild Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Mounting Type | External Mounting Brackets |
Series | nVent IS/GSC |
Size | 10.00 or 12.00 inches |
Thickness | 51.40mm (2.024") |
Thickness | 14 ga |
Thickness | 1.9 mm |
Type | External Mounting for Industrial Enclosures |
Use On | Instrumentation enclosures D12104IS through D12108IS |
Weight | 0.55 lb |
Width | 222 mm |
Width | 8.75 in |
Works With | NEMA |
Package Dimensions (L x W x H) | 9 IN x 2.2 IN x 0.9 IN |
Package Dimensions (L x W x H) | 22.86 cm x 5.588 cm x 2.286 cm |
Package Weight (Imperial) | 0.550 L |
Package Weight (Metric) | 0.250 kg |
How to Install the DMFK2 Mounting Foot Kit
This guide provides step-by-step instructions for installing the DMFK2 Mounting Foot Kit to secure your enclosure properly.
Estimated time: 30m
Tools needed:
Center punch, Drill, Screwdriver
Supplies needed:
Mounting foot studs, Sealing washers, Nuts
- Mark the mounting holes
Locate the holes for the mounting foot studs using the provided dimensions. Use a center punch to mark the centers of the holes.
- Drill the holes
Drill four holes with a diameter of .219 inches at the marked locations. Ensure that the drill is perpendicular to the surface.
- Insert mounting foot studs
Insert the mounting foot studs into the drilled holes. Turn the enclosure upright and lightly lubricate the sealing washers before pressing them onto the studs with the neoprene side facing down.
- Secure the studs
Thread the nuts onto the studs and tighten them to a torque of 15 to 20 in-lbs. Repeat this process for the other end to complete the installation.
