Overview
- Snap-in mounting provision holds cable manager in place while mounting screws are installed
- Robust arrowhead fingers are shaped to funnel cables into base and are made of black composite material
- Robust rounded end posts support cable as it enters and leaves cable manager and maintains proper cable bend radius
- Deep cable compartments allow maximum cable density
- Rounded edges throughout protect cable jackets from damage
- Pass-through holes on double-sided models protect cable while facilitating routing between front and back sides
- Single- and double-sided units provide high cable capacity, including 5e, 6 and 6A cables
- 1 RU and 2 RU heights allow greater flexibility in optimizing rack capacity
- Removable hinged cover opens top or bottom, snaps closed for assured cable protection and professional appearance
- Double-sided model has covers on both front and back
Specifications
Application | Networking, Storage and Data Center; Datacom and Telecom Equipment |
Color | Black |
Color | Jet Black |
Color Code | RAL 9005 |
Depth | 8.1 in |
Fill Rate, Front Cable, Cat 5e diam. 0.22 in | 416 |
Fill Rate, Front Cable, Cat 6 diam. 0.25 in | 322 |
Fill Rate, Front Cable, Cat 6A diam. 0.30 in | 224 |
Finish | Smooth Matte |
Front Cross-Section Area | 26.9 in² |
Material | ABS |
Material | Composite |
Modification Services | Yes |
Mounting Type | Tool-less mounting, 2- or 4-post open frame racks |
Product Family | CableTek |
Rack Units | 4 |
Series | CableTek |
Size | 4U, 19in |
Type | Rack and Cabinet Cable Management |
Weight | 4.8 lb |
Package Dimensions (L x W x H) | 19.3 IN x 9.1 IN x 8 IN |
Package Dimensions (L x W x H) | 49.022 cm x 23.114 cm x 20.32 cm |
Package Weight (Imperial) | 4.800 L |
Package Weight (Metric) | 2.177 kg |
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
PDCP2078
DataCom Enclosure Pkg, Bulletin DPVD (PROLINE® Voice and Data Package - PROLINE Voice and Data Package), Size/Dims: 2000x700x800mm, Material: Steel, Finish: Lt Gray
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
How to Install the CABLETEK™ Horizontal Cable Manager
This guide provides step-by-step instructions for mounting and securing the CABLETEK™ Horizontal Cable Manager to a frame.
Estimated time: 30m
Tools needed:
Screwdriver, Wire strippers
Supplies needed:
Mounting screws, Cage nuts (if required)
- Prepare the frame
Snap the horizontal cable manager onto the frame as shown in the installation diagram before proceeding with the screws.
- Select appropriate screws
Choose the screws based on the required thread pattern, typically 12−24 for racks and 10−32 for cabinets. Ensure cage nuts are available if needed.
- Secure the cable manager
Install the mounting screws through the cable manager into the frame, ensuring it is firmly attached and level.
