Overview
- Snap-in mounting provision holds cable manager in place while mounting screws are installed
- Robust arrowhead fingers are shaped to funnel cables into base and are made of black composite material
- Robust rounded end posts support cable as it enters and leaves cable manager and maintains proper cable bend radius
- Deep cable compartments allow maximum cable density
- Rounded edges throughout protect cable jackets from damage
- Pass-through holes on double-sided models protect cable while facilitating routing between front and back sides
- Single- and double-sided units provide high cable capacity, including 5e, 6 and 6A cables
- 1 RU and 2 RU heights allow greater flexibility in optimizing rack capacity
- Removable hinged cover opens top or bottom, snaps closed for assured cable protection and professional appearance
- Double-sided model has covers on both front and back
Specifications
Application | Networking, Storage and Data Center; Datacom and Telecom Equipment |
Color | Black |
Color | Jet Black |
Color Code | RAL 9005 |
Depth | 481 mm |
Depth | 18.93 |
Depth | 481 |
Fill Rate, Front Cable, Cat 5e diam. 0.22 in | 208 |
Fill Rate, Front Cable, Cat 6 diam. 0.25 in | 161 |
Fill Rate, Front Cable, Cat 6A diam. 0.30 in | 112 |
Finish | Smooth Matte |
Front Cross-Section Area | 13.2 in² |
Height | 201 mm |
Height | 7.9 |
Height | 201 |
Material | ABS |
Material | Composite |
Modification Services | Yes |
Mounting Type | Tool-less mounting |
Mounting Type | 19-Inch Rack Mount |
Product Family | CableTek |
Rack Units | 2 |
Series | CableTek |
Size | 2U |
Type | Rack and Cabinet Cable Management |
Weight | 2.3 lb |
Width | 88 mm |
Width | 3.47 |
Width | 88 |
Package Dimensions (L x W x H) | 21.4 IN x 7.9 IN x 4.6 IN |
Package Dimensions (L x W x H) | 54.356 cm x 20.066 cm x 11.684 cm |
Package Weight (Imperial) | 2.300 L |
Package Weight (Metric) | 1.043 kg |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
How to Install the CABLETEK™ Horizontal Cable Manager
This guide provides step-by-step instructions for mounting and securing the CABLETEK™ Horizontal Cable Manager to a frame.
Estimated time: 30m
Tools needed:
Screwdriver
Supplies needed:
Mounting screws, Cage nuts (if required)
- Prepare the frame
Ensure the frame is clean and free of debris. Identify the location where the horizontal cable manager will be installed.
- Snap the cable manager into place
Align the horizontal cable manager with the frame and snap it into place as shown in the installation diagram.
- Secure with screws
Using the appropriate screws (typically 12−24 for racks or 10−32 for cabinets), secure the cable manager to the frame. If cage nuts are required, ensure they are installed before securing the screws.
