Overview
- Drawn enclosure
- No welded seams or sharp corners
- Removable door with unique lift-off hinges
- Oil-tight quarter-turn slotted latches
- Oil-resistant gasket
- Weldnuts provided for mounting optional panels
- Bonding provision on door
Specifications
Application | Controls and Drives |
Color | Gray |
Color Code | ANSI 61 |
Conductive Panel | A12P10G |
Depth | 13 IN |
Depth | 6 in |
Depth, Maximum | 6 |
Depth, Minimum | 6 |
Finish | Powder Coated |
Height | 12 IN |
Height | 44 IN |
IP Rating | IP65 |
Material | Mild Steel;Steel |
Material | Steel |
Modification Services | Yes |
NEMA Rating | 12 |
Overall Dimensions | 12.09 x 10.45 in |
Overall Dimensions | 114 x 88 mm |
Panel | A12P10 |
Panel Size | 10.75 x 8.88 in |
Panel Size | 72.00 x 72.00 in |
Protection Rating | NEMA Type 12 |
Size | 12.00x10.00x6.00 in |
Thickness | 16 ga |
Thickness | 51.40mm (2.024") |
Type | Mild Steel Industrial Terminal and Junction Boxes |
Type | Mild Steel Terminal and Junction Boxes |
Type Number | Type 12 |
Weight | 9 lb |
Width | 254 mm |
Width | 10 IN |
Package Dimensions (L x W x H) | 12 IN x 10.7 IN x 7.3 IN |
Package Dimensions (L x W x H) | 30.48 cm x 27.178 cm x 18.542 cm |
Package Weight (Imperial) | 9.000 L |
Package Weight (Metric) | 4.082 kg |
How to Install the Mounting Foot Kit for DMFK1 and DMFK2
This guide provides step-by-step instructions for installing the mounting foot kit on your enclosure, ensuring a secure and stable setup.
Estimated time: 30m
Tools needed:
Center punch, Drill, Screwdriver
Supplies needed:
Mounting foot studs, Sealing washers, Nuts
- Locate and mark mounting holes
Identify the locations for the mounting foot studs using the provided dimensions. Use a center punch to mark the centers of the holes.
- Drill holes
Drill four holes with a diameter of .219 inches at the marked locations. Ensure the holes are clean and free of debris.
- Insert mounting foot studs
Insert the mounting foot studs into the drilled holes. Turn the enclosure upright and lightly lubricate the sealing washer, pressing it onto the mounting foot stud with the neoprene side facing down.
- Secure the studs
Thread the nut onto each stud and tighten to a torque of 15 to 20 in-lbs. Repeat this process for the other end to complete the installation.
