Contact for Pricing
Overview
- Aesthetic die-cast aluminum frame
- 0.188-in. (5-mm) thick, clear polycarbonate window
- Furnished window frame caps conceal mounting screws
- Available in ANSI 61 gray or RAL 7035 light gray finishes
- Optional locking (CWKL) or non-locking (CWKN) wing knob latches
Specifications
Application | Controls and Drives |
Color | ANSI 61 |
Color | Gray |
Color Code | ANSI 61 |
Finish | Powder Coated |
IP Rating | IP55 |
Material | Aluminum |
Modification Services | Yes |
Product Family | Concept |
Size | fits 400x450mm |
Thickness | 4 mm |
Thickness | 0.15 in |
Type | Industrial Door Mounting and Locks |
Type Number | Type 12 |
Weight | 6.4 lb |
Window Size | 343 x 366 mm |
Window Size | 13.50 x 14.40 in |
Works With | NEMA |
Package Dimensions (L x W x H) | 18.9 IN x 18.7 IN x 1.9 IN |
Package Dimensions (L x W x H) | 48.006 cm x 47.498 cm x 4.826 cm |
Package Weight (Imperial) | 6.400 L |
Package Weight (Metric) | 2.903 kg |
How to Install the CWH4045LG Controller
This guide provides step-by-step instructions for mounting, wiring, and configuring the CWH4045LG Controller.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the CWH4045LG controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the wiring
Use wire strippers to prepare the wires and connect them to the appropriate terminals on the controller. Ensure all connections are secure and insulated.
- Verify the connections
Use a multimeter to check the voltage and continuity of the connections. Ensure that all readings are within the specified range before powering on the controller.
- Power on the controller
Turn on the power supply to the controller and observe the startup sequence. Ensure that the controller initializes without errors.
- Configure the settings
Access the controller's configuration interface and set the desired parameters according to your application requirements.
- Calibrate the controller
Follow the calibration procedure outlined in the user manual to ensure accurate operation of the controller.
