Contact for Pricing
Overview
- Aesthetic die-cast aluminum frame
- 0.188-in. (5-mm) thick, clear polycarbonate window
- Furnished window frame caps conceal mounting screws
- 2-inch (51mm) space for switches, lights, meters, and other components
- Mounts with four screws; frame caps conceal hardware for clean installation
Specifications
Application | Controls and Drives |
Color | Light Gray |
Color | RAL 7035 |
Color Code | RAL 7035 |
Finish | Powder Coated |
IP Rating | IP55 |
Material | Aluminum |
Modification Services | Yes |
Nema Rating | Type 12 |
Product Family | Concept |
Size | 310x360mm |
Size | fits 310x360mm |
Thickness | 0.15 in |
Thickness | 4 mm |
Type | Industrial Door Mounting and Locks |
Type Number | Type 12 |
Weight | 4.6 lb |
Window Size | 9.96 x 10.86 in |
Window Size | 253 x 276 mm |
Works With | NEMA |
Package Dimensions (L x W x H) | 19.25 IN x 18.75 IN x 1.5 IN |
Package Dimensions (L x W x H) | 48.895 cm x 47.625 cm x 3.81 cm |
Package Weight (Imperial) | 4.600 L |
Package Weight (Metric) | 2.087 kg |
How to Install the CWH3136LG Controller
This guide provides step-by-step instructions for mounting, wiring, and configuring the CWH3136LG Controller.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the CWH3136LG controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the wiring
Use terminal connectors to attach the power and signal wires to the designated terminals on the controller. Ensure all connections are tight and secure.
- Verify connections
Utilize a multimeter to check the voltage at the terminals to ensure proper power supply. Confirm that all connections are correct before powering on the controller.
- Configure the controller
Follow the manufacturer's instructions to program the controller settings according to your application requirements. Adjust parameters as necessary.
- Calibrate the system
Perform any necessary calibration procedures as outlined in the user manual to ensure the controller operates accurately within the specified parameters.
