nVent CVR1008R5 - Ventilation Roofs, CVR, 58x1000x800mm, Zinc Plated, Mild Steel
nVent

CVR1008R5

UPC: 783510463922

Documents & Media
Installation Instructions

Contact for Pricing

Overview

Enhance your industrial enclosures with the nVent CVR Ventilation Roof Plate (SKU: CVR1008R5), a robust solution designed for effective natural ventilation while providing essential protection against environmental contaminants. Engineered by nVent, a trusted leader in electrical enclosure solutions, this roof plate offers a cost-effective and reliable method for managing airflow and maintaining optimal internal conditions within your equipment housings. The CVR1008R5 is specifically designed to facilitate natural convection, allowing hot air to escape and cooler, fresh air to enter, thereby preventing overheating and condensation. This passive ventilation approach is ideal for applications where active cooling systems are not feasible or desirable, contributing to energy efficiency and reduced operational complexity. Its substantial dimensions of 1000x800mm provide ample surface area for effective air exchange, making it suitable for a wide range of industrial enclosures, control cabinets, and machinery housings. Constructed from durable, zinc-plated mild steel, this ventilation roof plate offers excellent resistance to corrosion and environmental wear, ensuring long-term performance in demanding industrial settings. The zinc plating provides a protective barrier against moisture and chemical exposure, crucial for maintaining the integrity of sensitive electrical and electronic components housed within. The robust construction guarantees structural stability and reliable operation under various industrial conditions. Beyond its primary ventilation function, the nVent CVR Ventilation Roof Plate acts as a critical barrier, effectively preventing the ingress of insects, dust, and other airborne debris. This protection is vital for safeguarding the internal components of your enclosures from damage, malfunction, and premature failure. By maintaining a cleaner internal environment, you reduce the need for frequent maintenance and extend the operational lifespan of your equipment. Key features and benefits include: * **Effective Natural Ventilation:** Promotes airflow to prevent overheating and condensation. * **Environmental Protection:** Shields enclosures from insects, dust, and debris. * **Durable Construction:** Made from zinc-plated mild steel for corrosion resistance. * **Cost-Effective Solution:** Offers reliable passive ventilation without active power consumption. * **Versatile Application:** Suitable for a wide array of industrial enclosures and cabinets. * **Manufacturer Reliability:** Backed by nVent's expertise in enclosure accessories. The installation of the CVR1008R5 is straightforward, designed to integrate seamlessly with standard enclosure designs. Professionals in electrical engineering, automation, and industrial maintenance rely on nVent products for their quality, performance, and ease of use. Whether you are protecting sensitive control systems, power distribution units, or telecommunications equipment, the nVent CVR Ventilation Roof Plate is an indispensable component for ensuring operational reliability and longevity. Its origin in the US further underscores a commitment to quality manufacturing standards.
  • Durable zinc-plated mild steel construction for corrosion resistance.
  • Facilitates cost-effective natural ventilation, preventing overheating.
  • Protects internal components from insects, dust, and debris ingress.
  • Generous 1000x800mm dimensions for broad enclosure coverage.
  • Reliable performance backed by nVent's industry-leading expertise.
  • Pack quantity: 1 piece with mounting brackets and ventilation filter.
  • Note: Increases the enclosure height by 40 mm.

Specifications

Application
Power Distribution; Controls and Drives; Factory Automation and Process Control
Application
Controls and Drives; Factory Automation and Process Control
Color
Light Gray
Color
RAL 7035 Light Gray
Color Code
RAL 7035
Consist of
Ventilation Roofs; Mounting Components and Instruction Manual
Construction
16 gauge
Depth
800 mm
Depth
31.5 in
Enclosure Material
Mild Steel
Finish
Powder Coated
Height
58 mm
Height
2.28 in
Material
Mild Steel
Package Quantity
1
Product Family
Free-Standing
Size
2.28 x 39.37 x 31.5 inch
Thickness
1.5 mm
Thickness
16 ga
Type
IEC Enclosure Accessories
Type
Climate Control
Weight
25.1 lb
Weight
11.4 kg
Width
1,000 mm
Width
39.37 in
Works With
IEC
Package Dimensions (L x W x H)
39.75 IN x 1 IN x 40 IN
Package Dimensions (L x W x H)
100.965 cm x 2.54 cm x 101.6 cm
Package Weight (Imperial)
25.100 L
Package Weight (Metric)
11.385 kg
