Contact for Pricing
Overview
- Clean Tray Enclosure Adapters are used For securely connecting Clean Tray to an enclosure
- The Clean Tray stainless steel system is designed to protect rated cabling in applications that require frequent washdown
- Secure interface for nVent Clean Tray cable management system
- Superior corrosion resistance to chemicals and cleaning agents
- Compatible with standard enclosure interfaces for easy integration
Specifications
Application | Power Distribution; Corrosive Environments; Hygienic Environments |
Color | Brushed |
Color | Unpainted |
Finish | Brushed #3 |
Height | 4 IN |
Height | 102 mm |
Material | Stainless Steel |
Material | SS304 |
Modification Services | Yes |
NEMA Rating | 1 Indoor, electrical protection |
Product Family | CleanTray |
Protection Rating | NEMA Type 1 |
Series | CleanTray |
Size | 4.00x4.00 |
Thickness | 18 ga |
Thickness | 1.27 mm |
Type | Adapter |
Type | Industrial Lay-in Wireway |
Weight | 0.9 lb |
Width | 102 mm |
Width | 4 IN |
Wireway | Clean Tray Stainless Steel Cable Tray |
Package Dimensions (L x W x H) | 6.4 IN x 6.4 IN x 4.4 IN |
Package Dimensions (L x W x H) | 16.256 cm x 16.256 cm x 11.176 cm |
Package Weight (Imperial) | 0.900 L |
Package Weight (Metric) | 0.408 kg |
How to Install the CT46EIC45SS Controller
This guide provides step-by-step instructions for installing and configuring the CT46EIC45SS controller, ensuring proper wiring and setup for optimal performance.
Estimated time: 1h
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Wire connectors
- Mount the controller
Secure the CT46EIC45SS controller to the designated mounting surface using the provided mounting screws. Ensure it is level and firmly attached.
- Connect the power supply
Using wire connectors, connect the power supply wires to the controller's power terminals. Ensure the connections are tight and insulated to prevent short circuits.
- Verify connections
Use a multimeter to check the voltage at the power terminals of the controller. Ensure the voltage matches the specifications outlined in the user manual.
- Configure initial settings
Power on the controller and access the configuration menu. Set the desired parameters according to your application requirements.
- Calibrate the controller
Follow the calibration procedure in the user manual to ensure the controller operates accurately. Adjust settings as necessary based on the calibration results.
