Overview
- Clean Tray U-Connectors are used For connecting Clean Tray fittings to straight sections
- The Clean Tray stainless steel system is designed to protect rated cabling in applications that require frequent washdown
- Provides excellent corrosion resistance for washdown and hygienic environments.
- UL Classified (File No. E263414) as an equipment grounding conductor.
- NEMA Type 1 rated for reliable performance in industrial applications.
- Ideal for food processing, pharmaceutical, and chemical facilities requiring frequent washdown
- Modular design allows for easy installation and system expansion
- Compatible with CleanTray front covers, inside covers, and outside covers
- Meets Type 1 industry standards for industrial applications
Specifications
Application | Power Distribution; Corrosive Environments; Hygienic Environments |
Color | Unpainted |
Color | Brushed |
Finish | Brushed #3 |
Height | 2 IN |
Height | 51 mm |
Material | Stainless Steel |
Material | SS304 |
Modification Services | Yes |
NEMA Rating | 1 Indoor, electrical protection |
Product Family | CleanTray |
Protection Rating | NEMA Type 1 |
Size | 2.00x2.00 |
Thickness | 1.27 mm |
Thickness | 18 ga |
Type | U-Connector |
Type | Industrial Lay-in Wireway |
Weight | 0.4 lb |
Width | 51 mm |
Width | 2 IN |
Wireway | Clean Tray Stainless Steel Cable Tray |
Package Dimensions (L x W x H) | 4.7 IN x 4.4 IN x 4.3 IN |
Package Dimensions (L x W x H) | 11.938 cm x 11.176 cm x 10.922 cm |
Package Weight (Imperial) | 0.400 L |
Package Weight (Metric) | 0.181 kg |
