Overview
- Minimum-width body flange provides maximum body opening
- External formed 90-degree body flange
- Panel mounting studs fit optional Concept panels and other accessories
- Mounting holes in back of body for direct mounting or for optional external mounting brackets
- Type 316 stainless steel hidden hinges promote clean aesthetic appearance
- Corner formed doors are interchangeable and easily removed by pulling clip-style hinge pins
- Provision on door (except when B = 12 inch (305mm)) for thermoplastic data pocket
- Provision on door (except when B = 12 inch (305mm)) for optional doorstop kit
- Quarter-turn latches furnished with flush slotted insert
- Seamless foam-in-place gasket
Specifications
Application | Controls and Drives;Corrosive Environments |
Application | Corrosive Environments; Controls and Drives |
Body Thickness | 1.59 mm |
Body Thickness | 16 ga |
Color | Unpainted |
Color | Brushed |
Color | Brushed Stainless |
Conductive Panel | CP3624G |
Depth | 10 IN |
Depth | 254 mm |
Door Thickness | 1.98 mm |
Door Thickness | 14 ga |
Finish | Brushed #4 |
Height | 914 mm |
Height | 36 in |
Ip Rating | IP66/IP67 |
IP Rating | IP66 |
Latch Quantity | 2 |
Latch Type | Quarter-turn |
Material | Type 316L Stainless Steel |
Material | Stainless 316 |
Material | 316 Stainless Steel |
Material | Stainless Steel 316L |
Material | Stainless Steel;Stainless Steel 316L |
Modification Services | Yes |
Mounting | 34.50 x 22.50 in |
Mounting | Wall Mounting Brackets Available |
Mounting Type | Wallmount |
Nema Rating | Type 4X |
NEMA Rating | 4X |
Nema Rating | Type 4X/Type 12/Type 13 |
NEMA Rating | 4X Watertight, corrosion-resistant |
Panel | CP3624 |
Panel Size | 34.20 x 22.20 in |
Panel Size | 869 x 564 mm |
Product Family | Concept |
Protection Rating | NEMA Type 3R |
Protection Rating | NEMA Type 12 |
Series | Concept Wallmount |
Size | 36.00x24.00x10.00 in |
Size | 36x24x10 inches |
Style | Quarter-turn |
Type | Stainless Steel Wall Mounted Industrial Enclosures |
Type Number | Type 3R |
Weight | 61 lb |
Width | 610 mm |
Width | 24 IN |
Package Dimensions (L x W x H) | 41 IN x 25 IN x 12.25 IN |
Package Dimensions (L x W x H) | 104.14 cm x 63.5 cm x 31.115 cm |
Package Weight (Imperial) | 61.000 L |
Package Weight (Metric) | 27.670 kg |
