nVent CSD30308LG - Concept Single-Door Enclosure, 30.00x30.00x8.00, Lt Gray, Steel
nVent

CSD30308LG

UPC: 783510160395

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The **nVent Concept Single-Door Enclosure (CSD30308LG)** is a premium, lightweight steel enclosure designed for secure housing of electrical and electronic components in industrial, commercial, and utility applications. With a sleek, modern design and durable construction, this enclosure combines functionality with aesthetic appeal, making it an ideal choice for professionals who demand both performance and visual integration in their installations. Engineered by nVent, a global leader in electrical and thermal management solutions, the Concept Series enclosures are built to meet the rigorous demands of modern industrial environments. The **30.00 x 30.00 x 8.00-inch** dimensions provide ample internal space for mounting circuit breakers, relays, PLCs, or other control components, while the **light gray steel** finish ensures corrosion resistance and a professional appearance that blends seamlessly with facility aesthetics. Key features of the **CSD30308LG** include **flush quarter-turn latches**, which offer a clean, tamper-resistant closure while enabling quick and tool-free access for maintenance or adjustments. The **streamlined styling** of the Concept Series is not just about aesthetics—it also reduces the risk of snagging or damage in high-traffic areas, ensuring longevity and reliability in demanding applications. The enclosure’s steel construction provides robust protection against physical impacts, dust, and moisture, meeting industry standards for durability. This enclosure is particularly well-suited for **control panels, automation systems, telecommunications hubs, and renewable energy installations**, where space efficiency and component organization are critical. Its compact yet spacious design allows for easy integration into tight spaces, such as machine enclosures, data centers, or utility cabinets, without sacrificing accessibility. The **light gray finish** is also highly reflective, reducing heat absorption in enclosed environments—a valuable feature for maintaining optimal operating temperatures for sensitive electronics. Installation is straightforward, thanks to the **pre-drilled mounting holes** and compatibility with standard DIN rail accessories. Professionals appreciate the **modularity** of the Concept Series, which allows for seamless expansion or reconfiguration as system requirements evolve. nVent’s reputation for innovation and reliability ensures that this enclosure meets or exceeds industry certifications, including UL and NEMA standards, providing peace of mind for engineers and facility managers. Whether you’re outfitting a **factory automation system, a commercial building’s electrical room, or a remote telecom site**, the **nVent Concept Single-Door Enclosure (CSD30308LG)** delivers the durability, accessibility, and professional finish required for long-term performance. Trusted by industry leaders worldwide, nVent’s enclosures are a testament to over a century of expertise in electrical protection and thermal management solutions.
  • Seams continuously welded and ground smooth
  • Corner-formed doors
  • Simple easy-to-remove and install hinge pins with built-in captivation clip
  • High-torque threadless studs and fasteners on door
  • Minimum-width body flange provides maximum door opening (210 degrees)
  • Door opens 210 degrees
  • External formed body flange
  • Panel mounting studs fit optional Concept panels and other accessories
  • Mounting holes in back of body for optional external wall-mount brackets
  • Removable door with hidden hinges for clean, aesthetic appearance

Specifications

Application
Controls and Drives
Body Thickness
16 ga
Body Thickness
14 ga
Body Thickness
1.9 mm
Color
Gray
Color
Grey
Color
Lt Gray
Color
Light Gray
Color Code
RAL 7035
Concept Panel
CP3030
Conductive Concept Panel
CP3030G
Depth
203 mm
Depth
8 mm
Door Thickness
1.9 mm
Door Thickness
14 ga
Finish
Powder Coated
Height
30 IN
Height
762 mm
IP Rating
IP66
Latch Quantity
2
Latch Style
Quarter-turn
Latch Type
Quarter-turn
Material
Steel
Material
Mild Steel
Modification Services
Yes
Mounting
Wall Mounting Brackets Available
Mounting
28.50 x 28.50 in
Mounting Type
Pre-drilled mounting holes, DIN rail compatible
NEMA Rating
12 Indoor, dust-resistant
NEMA Rating
12
Panel Size
28.20 x 28.20 in
Panel Size
716 x 716 mm
Product Family
Concept
Protection Rating
NEMA Type 12
Series
Concept Enclosure
Series
Concept Series
Size
30.00x30.00x8.00 in
Size
30.00x30.00x8.00
Size
30.00x30.00x8.00 inches
Type
Mild Steel Wall Mounted Industrial Enclosures
Type Number
Type 4
Weight
66 lb
Width
30 IN
Width
762 mm
Package Dimensions (L x W x H)
35 IN x 31.25 IN x 10 IN
Package Dimensions (L x W x H)
88.9 cm x 79.375 cm x 25.4 cm
Package Weight (Imperial)
66.000 L
Package Weight (Metric)
29.938 kg
Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum

14A0705

Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum
