Overview
- All mounting hardware and instruction is included
- 16-gauge steel construction with ANSI 61 gray polyester powder paint finish
- Integrated VELCRO® strips for keyboard attachment and sliding mouse tray with storage bracket
- Quarter-turn slotted latch for tool-free access and internal cable management hole with rubber plug
- Compatible with Concept HMI Enclosure Type 4 (600x198mm footprint)
- Designed for Concept HMI Enclosure Type 4, 600x198mm footprint
- Includes cable management hole with rubber plug
- Hinged cover supported by flexible cables for hands-free operation
Specifications
Application | Controls and Drives |
Color | Lt Gray |
Color | Light Gray |
Color Code | RAL 7035 |
Depth | 0.39 |
Depth | 10 |
Depth | 10 mm |
Finish | Powder Coated |
Height | 198 mm |
Height | 7.79 |
Height | 198 |
Material | Mild Steel |
Material | Steel |
Modification Services | Yes |
Mounting Type | Under Enclosure |
Product Family | Concept |
Size | 600x198mm |
Thickness | 1.9 mm |
Thickness | 14 ga |
Type | HMI Enclosure Systems |
Type | Other Accessories |
Weight | 3.9 lb |
Width | 600 mm |
Width | 23.62 in |
Works With | NEMA |
Package Dimensions (L x W x H) | 24.4 IN x 8.7 IN x 3.7 IN |
Package Dimensions (L x W x H) | 61.976 cm x 22.098 cm x 9.398 cm |
Package Weight (Imperial) | 3.900 L |
Package Weight (Metric) | 1.769 kg |
How to Install the OI Keyboard Shelf
This guide provides step-by-step instructions for mounting and wiring the OI Keyboard Shelf securely.
Estimated time: 30m
Tools needed:
Screwdriver, Wire strippers
Supplies needed:
Mounting screws, Cable ties
- Gather necessary tools and supplies
Collect all required tools and supplies listed above to ensure a smooth installation process.
- Mount the keyboard shelf
Secure the keyboard shelf to the designated mounting surface using the provided mounting screws. Ensure it is level and tightly fastened.
- Connect wiring
Use wire strippers to prepare the wires for connection. Connect the keyboard shelf wiring to the appropriate terminals, ensuring a secure fit.
- Organize cables
Use cable ties to neatly bundle and secure any excess wiring to prevent interference and ensure a tidy installation.
- Verify installation
Check all connections and ensure the keyboard shelf is securely mounted. Test the functionality to confirm proper operation.
