Overview
- Description: Wall mounting combining kit is to be used for baying two or more wall mounted enclosures together, side by side. This enables customers to create many more enclosure configurations than previously available.
- Material: EPDM rubber 10 mm thick.
- Pack quantity: Combining kit provided in a puzzle format, along with mounting accessories.
- Comment: You can combine any wall mounted enclosures if the height and depth or width and depth are identicaL
- Puzzle-piece design for versatile application across enclosure sizes
Specifications
Application | Factory Automation and Process Control; Controls and Drives |
Color | Black |
Depth | 5 mm |
Depth | 0.2 in |
Enclosure Material | Mild Steel |
Finish | Smooth |
Height | 794 mm |
Height | 31.26 in |
Material | Rubber |
Material | EPDM |
Mounting Type | Wall-mounted |
Package Quantity | 1 |
Product Family | Wall Mounted |
Series | CK |
Size | 794x269x5mm |
Thickness | 10 mm |
Thickness | 0.39 in |
Type | Baying |
Type | IEC Enclosure Accessories |
Weight | 0.2 kg |
Weight | 0.4 lb |
Width | 10.59 in |
Width | 269 mm |
Works With | IEC |
Package Weight (Imperial) | 0.400 L |
Package Weight (Metric) | 0.181 kg |
AL31BK
Latch, Slotted Insert, Black, Bulletin A80 (Accessories - Misc.), Size/Dims: fits DL Wall-Mtg. , Material/Finish: Steel/zinc
How to Install the CK01 Controller
This guide provides step-by-step instructions for mounting, wiring, and configuring the CK01 Controller on a DIN rail.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the CK01 controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the wiring
Use terminal connectors to connect the power supply and input/output wires to the designated terminals on the CK01 controller. Ensure all connections are tight and secure.
- Verify the installation
Use a multimeter to check the voltage at the power terminals to ensure proper connection. Confirm that the controller powers on and all indicators are functioning.
