nVent CIWR8198 - Reducer 19-Inch Width, CIWR, 80x761x100mm, Light Gray, Mild Steel
nVent

CIWR8198

UPC: 783510459017

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The nVent CIWR8198 reducer (SKU CIWR8198) is a structural mounting solution designed to enable the installation of standard 19-inch rack equipment within 800mm-wide enclosures. This reducer features a 19-inch width and measures 80mm in depth, 761mm in height, and 100mm in width, providing a precise fit for nVent’s CIWR enclosure series. Constructed from 2mm zinc-plated mild steel, it delivers robust durability and corrosion resistance, further enhanced by a light gray powder-coated finish for long-term protection in demanding environments. Engineered for high load-bearing capacity, the CIWR8198 supports equipment loads up to 5000N when installed with two reducers or 8000N when paired with three, ensuring stability under heavy or vibrating conditions. Its design allows for installation at partial or full height, offering flexible mounting options to accommodate various 19-inch profile configurations within the enclosure. Ideal for applications in data centers, server rooms, and factory automation, this reducer reinforces 19-inch profiles, maintaining structural integrity and equipment alignment. The CIWR8198 is supplied as a single pair, including all necessary mounting accessories, simplifying integration and ensuring reliable performance in industrial and IT environments.
  • Description: Used to obtain 19" mounting facilities in 800 mm wide enclosures. Allows the mounting of CIP/CIPP profiles on partial or full height at any depth.
  • Material: 1.5 mm zinc plated steel.
  • Maximum load: Maximum supported weight is 5000N on 2 pair of CIWR and 8000N on 3 pair of CIWR.
  • Pack quantity: 1 pair with mounting accessories.
  • Maximum load: Maximum supported weight is 5000N (1124) on 2 pair of CIWR and 8000N (180) on 3 pair of CIWR

Specifications

Application
Controls and Drives;Factory Automation and Process Control
Color
Unpainted
Color
Light Gray
Construction
14 gauge
Depth
3.94
Depth
100
Depth
31.5 in
Depth
800 mm
Enclosure Material
Mild Steel
Finish
Zinc Plated
Height
80 mm
Height
3.15
Height
80
Material
Mild Steel
Mounting Plate Width
0.75 in
Mounting Type
Partial or Full Height
Mounting Type
Enclosure Frame Mounting
Mounting Type
Frame Mount
Package Quantity
2
Product Family
Free-Standing
Series
CIWR
Size
80x761x100mm
Size
3.15 x 29.96 x 3.94 inch
Thickness
14 ga
Thickness
51.40mm (2.024")
Type
IEC Enclosure Accessories
Type
Mounting
Weight
32 lbs./100ft
Weight
4.4 lb
Width
29.96
Width
761
Width
31.5 in
Width
800 mm
Works With
IEC
Package Weight (Imperial)
4.400 L
Package Weight (Metric)
1.996 kg
Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum

14A0705

Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.

BX4

Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black

LH38

Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
EP-RJG-M20-BL-A

1SNG618003R0000

EP-RJG-M20-BL-A
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey

LN43DA

1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey

LT20D-NEW

1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
External operation handle 0-1 type S01 Red Nema 4,4x

140E2911

External operation handle 0-1 type S01 Red Nema 4,4x
Escutcheon black type B for Sircover 125-630A

44095015

Escutcheon black type B for Sircover 125-630A
12,80" x 12,80" filter fan - 115Vac - 285.3 cfm - RAL 7035 - Type 12

FF20A115UE1

12,80" x 12,80" filter fan - 115Vac - 285.3 cfm - RAL 7035 - Type 12
5,90" x 5,90" filter fan - 24Vdc - 20.6 cfm - RAL 9005 - Type 3R - IP55

FF12D24NN53

5,90" x 5,90" filter fan - 24Vdc - 20.6 cfm - RAL 9005 - Type 3R - IP55
