Overview
- Manages 100kW+ of processor load per network
- Compatible with ASHRAE W4 warm water cooling
- N+1 redundant centralized pumps
- Dry-break quick disconnects (optional)
- 5-inch LCD screen with touch functionality
- Integrated control and monitoring system (Webserver, Modbus, SNMP)
- Internal and external leak detection system
- 4U rack-mount chassis
- Warm water cooling reduces the need for chillers
- Quick and easy installation and service
Specifications
Application | Networking, Storage and Data Center; Datacom and Telecom Equipment; Telecom and Data Protection |
Color | Jet Black |
Color Code | RAL 9005 |
Depth | 950 mm |
Depth | 37.4 in |
Finish | Plated |
Height | 177 mm |
Height | 6.97 in |
Material | Mild Steel |
Product Family | RackChiller CDU |
Rated Frequency | 50-60 Hz |
Rated Load Current Range | 10-15 A |
Series | RackChiller CDU100 |
Size | 4U |
Style | Unfilled, with CGB25 |
Type | Liquid Cooling |
Voltage Rating | 100-240 V |
Volume | 15.6 l |
Volume | 4.12 fl oz (US) |
Weight | 137 lb |
Width | 430 mm |
Width | 16.93 in |
Package Dimensions (L x W x H) | 17 IN x 7 IN x 37.5 IN |
Package Dimensions (L x W x H) | 43.18 cm x 17.78 cm x 95.25 cm |
Package Weight (Imperial) | 167.000 L |
Package Weight (Metric) | 75.751 kg |
RCH24001
The nVent RCH24001 is a high-quality industrial component designed for durability and efficiency in challenging environments. Engineered to meet rigorous performance standards, this product ensures reliable operation in critical applications. Its robust construction and precision engineering make it ideal for industrial settings where dependability is paramount. Trust nVent for solutions that deliver consistent performance and long-term value.Frequently Asked Questions
What is the heat load capacity of the RackChiller CDU100?
The RackChiller CDU100 is capable of managing 100kW+ of heat load.
What type of water does the CDU100 use for cooling?
It is compatible with ASHRAE W4 warm water cooling.
What is the rated voltage and frequency for the CDU100?
The rated voltage is 100 – 240V and the rated frequency is 50 – 60Hz.
What is the rated load current range for the CDU100?
The rated load current range is 10 – 15A.
What is the weight of the CDU100?
The CDU100 weighs 137lb.
What is the chassis size of the CDU100?
The CDU100 features a 4U rack-mount chassis.
Does the CDU100 include leak detection?
Yes, it has an internal and external leak detection system.
What is the color of the CDU100?
The CDU100 is Jet Black with a color code of RAL 9005.
What are the physical dimensions of the CDU100?
The CDU100 has a height of 6.97 inches, a width of 16.93 inches, and a depth of 37.4 inches.
Does the CDU100 have pump redundancy?
Yes, it features N+1 redundant centralized pumps, with 2 pumps for redundancy.
