Overview
- Kits include slide mechanisms and hardware
- Use two kits when enclosure has six collar studs for mounting panel
- Kit catalog numbers ending in 2 contain two slide mechanisms; catalog numbers ending in 4 contain four slide mechanisms
- Designed for nVent CONCEPT enclosures with a 20.00-inch depth.
- Facilitates optimized space, airflow, and maintenance within industrial enclosures.
Specifications
Application | Controls and Drives |
Color | Unpainted |
Finish | Plated |
Fits Concept Enclosure | When C = 20.00 in |
Fits Concept Enclosure | When C = 508 mm |
Fits Depth | 20 in |
Fits Depth | 9.84 in |
Material | Mild Steel |
Material | Plated Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Mounting Type | Adjustable-depth mounting kit with slides |
Product Family | Concept |
Series | nVent Concept |
Size | fits 20.00 deep + in |
Size | 20.00 inches depth |
Type | Industrial Panels and Panel Accessories |
Weight | 3 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 25.9 IN x 4.5 IN x 2.9 IN |
Package Dimensions (L x W x H) | 65.786 cm x 11.43 cm x 7.366 cm |
Package Weight (Imperial) | 3.000 L |
Package Weight (Metric) | 1.361 kg |
