Contact for Pricing
Overview
- Kits include slide mechanisms and hardware
- Use two kits when enclosure has six collar studs for mounting panel
- Kit catalog numbers ending in 2 contain two slide mechanisms; catalog numbers ending in 4 contain four slide mechanisms
- Durable plated steel construction for industrial environments
- Manufactured in the United States
Specifications
Application | Controls and Drives |
Color | Unpainted |
Finish | Plated |
Fits Concept Enclosure | When C = 254 mm |
Fits Concept Enclosure | When C = 10.00 in |
Fits Depth | 9.84 in |
Fits Depth | 10 in |
Material | Steel |
Material | Mild Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Mounting Type | Adjustable-Depth Mounting Kit |
Product Family | Concept |
Series | Concept Adjustable-Depth Mounting Kits |
Size | fits 10.00 deep + in |
Size | 10.00 deep |
Type | Industrial Panels and Panel Accessories |
Weight | 1.8 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 13.4 IN x 4.5 IN x 3 IN |
Package Dimensions (L x W x H) | 34.036 cm x 11.43 cm x 7.62 cm |
Package Weight (Imperial) | 1.800 L |
Package Weight (Metric) | 0.817 kg |
How to Install the CAM124 Controller
This guide provides step-by-step instructions for installing and configuring the CAM124 Controller on a DIN rail.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the CAM124 controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the power supply
Use terminal connectors to connect the power supply wires to the designated terminals on the CAM124. Verify that the connections are secure and insulated.
- Configure the controller settings
Power on the CAM124 and use the configuration interface to set the desired parameters. Follow the on-screen prompts to complete the setup.
- Calibrate the controller
Perform a calibration by following the calibration procedure in the user manual. Ensure all readings are accurate before finalizing the installation.
Frequently Asked Questions about nVent
What industries and applications are nVent products used for?
nVent products are engineered for critical infrastructure and industrial applications across multiple demanding sectors. Key markets include Construction, Data Centers, Defense, Healthcare, Mining, Oil & Gas Refineries, Power Plants, Rail/Transit, Renewable Energy, Security, Ship Building, Steel Mills, Telecom, and Utilities. Their solutions are designed to withstand extreme environmental conditions, with temperature ranges from -55°C to 105°C and specialized features like UV resistance, oil resistance, and flame resistance.
What environmental ratings do nVent products have?
nVent enclosures feature comprehensive environmental ratings, including UL 508A, CSA, and NEMA Type 1, 2, 3, 4, 4X, 12, and 13 certifications. They are rated IEC 60529 IP66, providing robust protection against dust, water, and corrosion in both indoor and outdoor environments. These products operate effectively in temperatures ranging from -40°F to 266°F, with enhanced UV inhibitors for outdoor weathering and oil-resistant gaskets for superior sealing.
What accessories are available for nVent products?
nVent offers a comprehensive range of accessories across multiple product lines, including EMC accessories like bonding cable clamps and strain reliefs, inline accessories such as lock inserts and mounting brackets, CONCEPT accessories including panel conversion kits and rack-mount angles, and seismic accessories for specialized mounting requirements. Key accessory categories include grounding kits, DIN rail mounting solutions, panel supports, handles, and various mounting hardware compatible with different enclosure types.
What certifications and standards do nVent products comply with?
nVent products meet critical international certifications including UL (United States), CSA (Canada), CE (European Community), and EAC (Russia). Our products are designed to comply with rigorous industrial standards such as NEMA enclosure ratings, IEC 60529 IP ratings, and international safety standards across multiple industrial markets including oil & gas, power, manufacturing, and infrastructure.
What is nVent's warranty policy?
nVent offers a standard 18-month warranty from invoicing date for most automation products, covering defects in workmanship and materials. The warranty requires proper transportation, handling, storage, and installation within specified environmental conditions. Warranty coverage includes repair or replacement at nVent's discretion, with certain conditions such as authorized service repairs and operation within designed capacity limits.
What technical support does nVent offer?
nVent offers comprehensive technical support through multiple global contact centers across North America, South America, Europe, Middle East, India, and Asia. Customers can reach technical experts by phone at regional numbers, with the North American headquarters in Minneapolis, MN providing primary support at +1.763.421.2240. Additionally, nVent provides online support resources through their website, including CAD drawing downloads and an 'Ask The Expert' feature to assist with product technical inquiries.
