Contact for Pricing
Overview
- Mounting hardware included
- Custom sizes, materials, finishes, etc., can be provided on special order
- ANSI 61 gray polyester powder finish
- 4 louvers for effective airflow
- Includes mounting hardware for field installation
Specifications
Application | Power Distribution; Controls and Drives |
Color | Gray |
Color Code | ANSI 61 |
Depth | 6 mm |
Depth | 0.25 in |
Finish | Powder Coated |
Height | 4.75 in |
Height | 121 mm |
L | 76 mm |
L | 3 in |
Louvre Quantity | 4 |
Material | Mild Steel |
Material | Steel |
Size | 4.75 x 4.50 in |
Thickness | 1.9 mm |
Thickness | 14 |
Thickness | 1.9 |
Thickness | 14 Gauge |
Type | Cooling Accessories |
Usable Area | 1.76 in² |
Usable Area | 11.35 cm² |
Weight | 0.48 lb |
Width | 114 mm |
Width | 4.5 |
Width | 114 |
Width | 4.5 in |
Package Dimensions (L x W x H) | 10.3 IN x 8 IN x 0.2 IN |
Package Dimensions (L x W x H) | 26.162 cm x 20.32 cm x 0.508 cm |
Package Weight (Imperial) | 0.480 L |
Package Weight (Metric) | 0.218 kg |
