Contact for Pricing
Overview
- Seams are continuously welded and ground smooth
- Body stiffeners in larger enclosures for extra rigidity
- Body flange trough excludes liquids and contaminants
- Heavy-duty lifting eyes anchor into reinforced top
- Concealed, easy-to-remove hinges
- Heavy-duty 3-point latching mechanism operated by padlocking handle on all doors
- Order panels separately
- Data pocket is high-impact thermoplastic
- Oil-resistant door gasket
- Bonding provision on door
Specifications
Application | Arc Flash Safety; Power Distribution; Controls and Drives |
Body Thickness | 12 ga |
Body Thickness | 2.66 mm |
Cable Entry | No |
Color | Unpainted |
Color | None |
Conductive Panel | A72PM40G |
Connection | Yes |
Cubic Capacity | 30 Cu-Ft |
Depth | 18.11 |
Depth | 460 |
Depth | 460 mm |
Door Thickness | 2.66 mm |
Door Thickness | 12 ga |
Finish | Brushed |
Height | 72.13 |
Height | 1,832 |
Height | 1,832 mm |
Insulation | False |
Insulation | No |
Material | Stainless Steel 304 |
Mounting | Free Standing |
NEMA Rating | Type 4X, 4, 12, 3R |
Number Of Outlet | 2 |
Painted Panel | A72PM40 |
Panel Size | 1524 x 857 mm |
Panel Size | 60.00 x 33.75 in |
Protection Rating | NEMA Type 4 |
Size | 72.13 x 39.76 x 18.11 inch |
Type | Stainless Steel Freestanding Industrial Enclosures |
Weight | 337.82 lb |
Width | 1,010 mm |
Width | 39.76 |
Width | 1,010 |
Package Dimensions (L x W x H) | 56 IN x 34 IN x 82 IN |
Package Dimensions (L x W x H) | 142.24 cm x 86.36 cm x 208.28 cm |
Package Weight (Imperial) | 337.820 L |
Package Weight (Metric) | 153.235 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the AU72X4018BSSLP Controller
This guide provides step-by-step instructions for installing and configuring the AU72X4018BSSLP controller, including wiring and calibration.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the AU72X4018BSSLP controller to the designated mounting surface using the provided mounting screws. Ensure the controller is level and firmly attached.
- Connect the wiring
Using wire strippers, prepare the wires for connection. Connect the power and signal wires to the appropriate terminals on the controller, ensuring correct polarity.
- Verify connections
Use a multimeter to check the voltage at the terminals to ensure proper power supply. Confirm that all connections are secure and correctly wired.
- Configure the controller
Access the controller's configuration interface and input the necessary parameters for operation, such as communication settings and operational modes.
- Calibrate the controller
Follow the calibration procedure outlined in the user manual to ensure accurate readings and performance. Adjust settings as necessary based on the calibration results.
