Contact for Pricing
Overview
- Temperature (32-140 F) and humidity (50%-90% RH) adjustment
- High switching capacity
- Optical function displays (LED) in each control
- Mounting clip for 35-mm DIN rail
- Change-over contact (relay)
- Connection is a 5-pole terminal for AWG 14 max (2.5-mm square); clamping torque .5 Nm (4.4 in-lbs) maximum
- Plastic housing UL94V-0
- Vertical mounting
- Operating voltage is AC 100-240 V with maximum switching capacity of 10 A resistive / 1.6 A inductive at AC 240 V
Specifications
Application | Controls and Drives;Power Distribution |
Color | Light Gray |
Color | Gray |
Color | Grey |
Color Code | RAL 7035 |
Depth | 43 mm |
Depth | 1.69 in |
Finish | Smooth Matte |
Height | 77 mm |
Height | 3.03 in |
Input Voltage AC | 100-120 V |
Material | Plastic |
Size | 3.03 x 2.36 x 1.69 in |
Type | Cooling Accessories |
Voltage AC | 100 - 120 VAC |
Voltage Rating | 100 - 120 VAC |
Weight | 0.2 lb |
Width | 60 mm |
Width | 2.36 IN |
Package Dimensions (L x W x H) | 3.4 IN x 2.4 IN x 1.75 IN |
Package Dimensions (L x W x H) | 8.636 cm x 6.096 cm x 4.445 cm |
Package Weight (Imperial) | 0.200 L |
Package Weight (Metric) | 0.091 kg |
How to Install the Electronic Temperature and Humidity Regulator
This guide provides step-by-step instructions for installing and configuring the electronic temperature and humidity regulator in a closed electric cabinet.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the regulator
Secure the regulator vertically in the upper area of the electric cabinet, ensuring that the connection terminals are oriented downwards and that it is positioned away from heat-generating components.
- Connect the wiring
Use appropriate wire gauges (solid AWG 14 maximum or stranded AWG 16 maximum) to connect the terminals 5-3 for the temperature and humidity functions. Ensure correct polarity to avoid equipment damage.
- Configure the settings
Adjust the temperature and humidity dials to the desired reference values. Verify that the LED indicators illuminate correctly when the conditions exceed the set thresholds.
