Overview
- Tilt allows forward and backward movement up to 30 degrees from horizontal
- Swivel allows 350-degree maximum rotation
- Integral stops at 30-degree increments between 60 degrees and 180 degrees of rotation
- Hardware and gasket to attach enclosure are included
- Do not use the swivel between an overhead support and an enclosure
- Do not use the swivel between an overhead support and an enclosure
Specifications
Application | Controls and Drives |
Color | Unpainted |
Depth | 102 mm |
Depth | 4 in |
Finish | Anodized |
Height | 5.81 in |
Height | 44 IN |
Material | Aluminum |
Max Enclosure Size | 24.00 x 24.00 x 16.00 in |
Max Enclosure Size | 838 x 610 x 610 mm |
Max Load, Including Enclosure | 75 lb |
Max Load, Including Enclosure | 90.7 kg |
Modification Services | Yes |
Size | 5.81x4.00x4.00 in |
Thickness | 0.15 in |
Thickness | 51.40mm (2.024") |
Type | Pedestals |
Weight | 6.2 lb |
Width | 102 mm |
Width | 4 IN |
Package Dimensions (L x W x H) | 8.3 IN x 6.4 IN x 4.5 IN |
Package Dimensions (L x W x H) | 21.082 cm x 16.256 cm x 11.43 cm |
Package Weight (Imperial) | 6.200 L |
Package Weight (Metric) | 2.812 kg |
