Contact for Pricing
Overview
- Innovative 3-in-1 self-centering design reduces inventory requirements; 3 models cover 9 common industry cutouts ranging from 1/2 inch (13mm) to 2-1/2 inch (64mm)
- Non-metallic construction provides superior corrosion resistance for reliability in harsh environments
- UV stabilized; ideal for direct sunlight (avoids fiberbloom associated with fiberglass)
- Chemically resistant to a broad range of chemicals
- Durable and impact resistant; resists cracking
- Sold in quantities of 2 per catalog number
- Cost-effective alternative to stainless steel
- Polyester material has a UL 94 rating of 5VA
- Easy to install; no tools required
- Thread and nut are constructed of non-glass-filled polyester
Specifications
Accessory Type | Hole Seals |
Application | Controls and Drives;Corrosive Environments;Power Distribution |
Application | Corrosive Environments; Controls and Drives; Power Distribution |
Color | Gray |
Color | Light Gray |
Color Code | RAL 7035 |
Finish | Textured |
IP Rating | IP66 |
Material | Non-glass-filled polyester |
Material | Plastic;Polyester |
Material | Polyester |
Material | Non-Metallic |
Min Hole Diameter | 33 mm |
Modification Services | Yes |
Mounting Type | Tool-free installation |
Nema Rating | Type 3R, 4, 4X, 12, 13 |
Outside Diameter | None |
Outside Diameter | 1.56 in |
Product Family | Hol-Sealers |
Size | 1.57 Dia. in |
Size | 40x33x3 mm |
Thickness | 0.12 in |
Thickness | 51.40mm (2.024") |
Torque | 15 lbf/in |
Type | External Mounting for Industrial Enclosures |
Weight | 0.1 lb |
Works With | NEMA / IEC |
Package Dimensions (L x W x H) | 6 IN x 5.25 IN x 1.5 IN |
Package Dimensions (L x W x H) | 15.24 cm x 13.335 cm x 3.81 cm |
Package Weight (Imperial) | 0.100 L |
Package Weight (Metric) | 0.045 kg |
How to Install the ASPB05075NM Controller
This guide provides step-by-step instructions for installing and configuring the ASPB05075NM Controller on a DIN rail.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the ASPB05075NM controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the wiring
Use terminal connectors to connect the power supply and input/output wires to the designated terminals on the controller. Ensure all connections are tight and secure.
- Verify the installation
Use a multimeter to check the voltage at the power terminals to ensure proper power supply. Confirm that the controller is receiving the correct voltage as specified in the documentation.
