Overview
- Use 4.00 x 4.00-in. (102 x 102-mm) pedestal with Concept HMI and InLine HMI Enclosures
- Use 8.00 x 8.00-in. (203 x 203-mm) pedestal with ProLine Sloped-Front HMI Enclosures
- Attach pedestal to HMI base with cutout, swivel, swivel tilt or angle adapter with pre-drilled holes
- Hardware and gasket to attach enclosure are included
- Tapped mounting holes for HMI adapters
- Compatible with 4.00 x 4.00-in. nVent CONCEPT and INLINE HMI Enclosures.
- Manufactured in the USA by nVent.
Specifications
Application | Controls and Drives |
Color | Gray |
Color | Ansi 61;Gray |
Color Code | ANSI 61 |
Depth | 102 mm |
Depth | 4 in |
Finish | Powder Coated |
Height | 584 mm |
Height | 23 IN |
Height | 44 IN |
Material | Mild Steel;Steel |
Material | Mild Steel |
Material | Steel |
Modification Services | Yes |
Mounting Type | Bolt-Down |
Series | AP |
Size | 23.00x4.00x4.00 in |
Size | 23.00x4.00x4.00 |
Size | 23.00" H x 4.00" W x 4.00" D |
Thickness | 1.9 mm |
Thickness | 14 ga |
Thickness | 51.40mm (2.024") |
Type | Pedestals |
Weight | 11.6 lb |
Width | 102 mm |
Width | 4 IN |
Package Dimensions (L x W x H) | 37.25 IN x 6.3 IN x 6.3 IN |
Package Dimensions (L x W x H) | 94.615 cm x 16.002 cm x 16.002 cm |
Package Weight (Imperial) | 11.600 L |
Package Weight (Metric) | 5.262 kg |
44-BL
Bar Hanger, Length 26 Inches, Steel, Deep Offset 1-1/2 Inch for Mounting 1-1/2 Inch Deep Boxes with Plaster Ring, Furnished with Stove bolt
AB253
The NEMA 3R enclosures feature a standard padlock-able handle feature. They are galvanised steel coated with Pulvalar 115 powder
BMB244S4P
Electrical box mounting bracket for mounting up to four 4 in. or 4 11/16 in. boxes or plaster rings. It is made of steel with a pre-galvanized silver finish. The bracket supports 1-1/2 or 2-1/8 in. deep boxes, plaster rings, or low voltage mounting devices from one bracket between studs. Dimensions are 24 in. length, 5 in. height, and 1/2 in. depth.
H8084HLL
8x8x4 Polycarbonate Enclosure NEMA 4X | Hinged Cover | Gray | Stainless Steel Locking Latch | Mounting Feet
