Contact for Pricing
Overview
- Proper installation will provide rainproof ventilation but will not meet Type 4 or 12 requirements
- Kit includes mounting hardware and instructions
- Supplied screws are 13-mm (.515-inch) long and some applications may require longer screws.
- Facilitates temperature and pressure equalization
- Easy installation with standard mounting hardware
Specifications
Application | Controls and Drives; Power Distribution |
Color | Gray |
Color | Light Gray |
Color Code | RAL 7035 |
Depth | 22 mm |
Depth | 0.87 in |
Finish | Smooth Matte |
Height | 27 mm |
Height | 1.08 in |
Material | Plastic |
Size | 1.08x0.90x0.87 |
Type | Fans and Filter Fans |
Type | Cooling Accessories |
Weight | 0.02 lb |
Width | 25 mm |
Width | 0.98 |
Width | 25 |
Package Dimensions (L x W x H) | 4 IN x 3.25 IN x 0.75 IN |
Package Dimensions (L x W x H) | 10.16 cm x 8.255 cm x 1.905 cm |
Package Weight (Imperial) | 0.020 L |
Package Weight (Metric) | 0.009 kg |
How to Install the Small Ventilator
Step-by-step guide for installing the Small Ventilator through an enclosure wall.
Estimated time: 15m
Tools needed:
Drill, Punch tool
Supplies needed:
Ventilator unit, Nut for fastening
- Prepare the enclosure wall
Drill or punch a hole in the enclosure wall according to the specified dimensions.
- Install the ventilator
Insert the ventilator unit through the hole in the enclosure wall.
- Secure the ventilator
Fasten the ventilator from the inside of the enclosure using the provided nut to ensure a tight fit.
