Contact for Pricing
Overview
- Each kit includes a handle, latch, latch rods, adjustable rod guides and all hardware
- These kits are available with a key locking handle, a non-locking handle or a padlocking handle
- Two keys are furnished with keylocking handles
- Adjustable latch rods for precise gasket compression
- Roller-equipped latch rods for smooth door operation
- Watertight and dust-tight seal for Type 12 enclosures
- Field-installable on most standard one-door Type 12 enclosures
- Not compatible with HOFFMAN disconnect, CONCEPT, or PROLINE enclosures
Specifications
Accessory Type | Locks, Lockouts, Latches, Handles and Clamps |
Application | Controls and Drives;Power Distribution |
Color | Black |
Finish | Powder Coated |
Handle Type | Non-Locking |
Material | Steel |
Material | Mild Steel |
Modification Services | Yes |
NEMA Rating | 12 Indoor, dust-resistant |
Nema Rating | Type 12 |
Opens | Clockwise |
Size | Ht=60to72 |
Type | Industrial Door Mounting and Locks |
Weight | 3.6 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 37.75 IN x 4.2 IN x 3 IN |
Package Dimensions (L x W x H) | 95.885 cm x 10.668 cm x 7.62 cm |
Package Weight (Imperial) | 3.600 L |
Package Weight (Metric) | 1.633 kg |
