Overview
- Kit contains a set of 10 screws, sealing washers and locking nuts
- Kits are offered in 10-32, 1/4-20 and 3/8-16 fastener sizes in stainless steel
- Sealing washer is stainless steel and has integral rubber sealing
- Kit contains screws, sealing washers and locking nuts
- Kit is UL-recognized as a means to maintain UL enclosure cabinet rating up to Type 4X
- Fasteners are made of stainless steel
- Sealing washer has integral rubber sealing and stainless steel washer
Specifications
Accessory Type | Hole Seals |
Application | Controls and Drives;Corrosive Environments;Power Distribution |
Application | Power Distribution; Controls and Drives; Corrosive Environments |
Color | Unpainted |
Color | Stainless Steel |
Drill Hole Size | 13/32 in |
Fastener Length | 1 in |
Finish | Tumbled |
Finish | Tumble |
Ip Rating | IP66/IP67 |
Material | Stainless Steel 304 |
Material | Stainless Steel;Stainless Steel 304 |
Modification Services | No |
Mounting Type | Screw Mounting |
Nema Rating | Type 4X |
Nominal Fastener Size | 3/8-16 |
Series | AHK |
Size | 3/8-16 IN |
Type | Other Accessories |
Weight | 0.64 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 7.25 IN x 5 IN x 0.5 IN |
Package Dimensions (L x W x H) | 18.415 cm x 12.7 cm x 1.27 cm |
Package Weight (Imperial) | 0.640 L |
Package Weight (Metric) | 0.290 kg |
How to Install the AHK38164X Controller
This guide provides step-by-step instructions for installing and configuring the AHK38164X Controller, ensuring proper setup and functionality.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the AHK38164X controller to the designated mounting surface using the provided mounting screws. Ensure it is level and securely fastened.
- Connect the wiring
Use wire strippers to prepare the wires and connect them to the terminal connectors on the controller. Ensure all connections are tight and secure to prevent any electrical issues.
- Verify the installation
Power on the AHK38164X controller and use a multimeter to check the voltage at the terminals. Ensure that the readings are within the specified range to confirm proper installation.
