Contact for Pricing
Overview
- Each kit includes two stands
- Two sets of floor stands are recommended for enclosures larger than double door Free-Stand enclosures
- Constructed from durable mild steel with ANSI 61 gray finish
- Stable, vibration-resistant bolt-on design for heavy-duty applications
- Ideal for retrofitting or new installations in industrial environments
Specifications
Accessory Type | Floor Stand Kits |
Application | Controls and Drives;Power Distribution |
Color | Gray |
Color Code | ANSI 61 |
Finish | Powder Coated |
Height | 44 IN |
Height | 24 in |
Height | 610 mm |
Material | Mild Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Size | 24.00x10.06 in |
Thickness | 51.40mm (2.024") |
Thickness | 2.66 mm |
Thickness | 12 ga |
Type | Base Mounting for Industrial Enclosures |
Weight | 45 lb |
Width | 256 mm |
Width | 10.06 in |
Works With | NEMA |
Package Dimensions (L x W x H) | 28 IN x 10 IN x 12.5 IN |
Package Dimensions (L x W x H) | 71.12 cm x 25.4 cm x 31.75 cm |
Package Weight (Imperial) | 45.000 L |
Package Weight (Metric) | 20.412 kg |
How to Install the AFK1224SS Enclosure
This guide provides step-by-step instructions for securely installing the AFK1224SS enclosure on a floor stand.
Estimated time: 1h
Tools needed:
Screwdriver, Drill, Torque wrench
Supplies needed:
3/8-inch diameter studs, 3/8−16x1.00 hex head screws, Washers, Nuts, Lockwashers
- Verify enclosure depth
Check the depth of the floor stand (”C” dimension) to ensure it matches the enclosure depth dimension.
- Anchor floor studs
Securely anchor six 3/8-inch diameter studs (not provided with kit) in the floor as shown in the installation diagram.
- Drill enclosure holes
Drill the appropriate hole pattern in the bottom of the enclosure as indicated in the installation diagram.
- Bolt floor stand to enclosure
Using the provided 3/8−16x1.00 hex head screws, washers, and nuts, bolt the floor stand to the enclosure. Firmly tighten all fasteners.
- Position the enclosure
Position the enclosure with the attached floor stands over the anchored floor studs, ensuring the studs extend through the base holes in the floor stands.
- Secure floor stands
Secure the floor stands to the anchored floor studs using 3/8 inch nuts and lockwashers or with 3/8 inch locknuts and washers. Torque to 120 in-lbs.
- Check electrical clearances
WARNING: To avoid electric shock, do not energize any circuits before checking all internal and external electrical and mechanical clearances to ensure safe operation.
