Contact for Pricing
Overview
- Includes four PolyPro Adjustable Panel Blocks. No enclosure modification is required for installation.
- 9.00 x 7.62 inch (229 x 194 mm) dimensions
- Adjustable height within top 5 inches via PolyPro rail system
- Supports installation of multiple panels
- No enclosure modification required for installation
- Includes four PolyPro Adjustable Panel Blocks and Allen wrench
Specifications
Application | Controls and Drives;Corrosive Environments |
Color | Unpainted |
Finish | Anodized |
Height | 9 IN |
Height | 44 IN |
Material | Anodized Aluminum |
Material | PolyPro |
Material | Aluminum |
Modification Services | Yes |
Mounting Type | Swing-Out Panel with Adjustable Blocks |
Mounting Type | Swing-Out Panel Adjustable |
Panel Size | 229 x 194 mm |
Panel Size | 9.00 x 7.62 in |
Product Family | PolyPro |
Series | PolyPro |
Size | 8.75x6.88 in |
Size | 8.75x6.88 |
Size | 9.00 x 7.62 in (229 x 194 mm) |
Thickness | 0.08 in |
Thickness | 51.40mm (2.024") |
Type | Industrial Panels and Panel Accessories |
Weight | 0.7 lb |
Width | 7.62 in |
Width | 193 mm |
Works With | NEMA |
Package Dimensions (L x W x H) | 11.25 IN x 9.25 IN x 1.5 IN |
Package Dimensions (L x W x H) | 28.575 cm x 23.495 cm x 3.81 cm |
Package Weight (Imperial) | 0.700 L |
Package Weight (Metric) | 0.318 kg |
How to Install the A64PSWPNL Controller
Complete installation guide for mounting and wiring the A64PSWPNL Controller on a DIN rail.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the A64PSWPNL controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the power supply
Use terminal connectors to connect the power supply wires to the designated terminals on the controller. Ensure the connections are tight and secure.
- Verify the connections
Use a multimeter to check the voltage at the power terminals to ensure proper power supply. Confirm that the voltage matches the specifications outlined in the documentation.
