Woodhead SY16-4 #16-4 YELLOW - SOW-A/SOW CORD BOXEDIN250'C
Alternate Item Number: 1301280140
UPC: 786788799601
Documents & Media
Contact for Pricing
Minimum Qty: 250
Multiplier: 1
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 250-foot boxed length for portable and industrial applications
- Operating temperature range: -40°C to 80°C
- 300V rating with 8A current capacity
- Oil, cutting fluid, and cut resistant for harsh environments
Specifications
Amperage Rating | 8 A |
Brand Name | Woodhead |
Color | Yellow |
Conductor Range | 16 |
Conductor Range, Maximum | 16 |
Conductor Range, Minimum | 16 |
Connection Type | SOW-A/SOW |
Finish | SOW,SOW-A |
Material | TPE |
Number Of Conductors | 4 |
Series | SY |
Size | 76.20m |
Size | #16-4 |
Sub Brand | Heavy Duty |
Temperature Rating | -40°C to +105°C |
Temperature Rating, Maximum | 221 F |
Temperature Rating, Maximum | 105 C |
Temperature Rating, Minimum | -40 F |
Temperature Rating, Minimum | -40 °C |
Temperature Rating, Minimum | -40 C |
Voltage Rating | 600V |
Package Weight (Imperial) | 0.119 L |
Package Weight (Metric) | 53.977 g |

115030K13M030
Mini-Change® A-Size Double-Ended Cordset, 5 Poles, Male (Straight) to Female (Straight), TC-EC Cable Type, 3.0m Length
PMINHW-34MFF-T-2M-C011
MIN Power Distribution Series , 3 Pole, Male to Female "T" with 7/8" Female drop cable, 2m, 14awg, 30A/18A, Black, TPE, TC-ER, FT4
RSK301
One-Piece Grounding Connector, Shield Diameter Range 3.66mm-5.12mm, Color Yellow, Copper, Tin Plated, Polyester InsulationFrequently Asked Questions
What is the operating temperature range for this cable?
The operating temperature range for this cable is -40°C to +105°C.
What is the maximum voltage this cable can handle?
The maximum voltage this cable can handle is 600V.
What is the wire size and type of this cable?
The wire size is 16 AWG and the wire/cable type is SOW, SOW-A.
How many conductors are in this cable?
This cable has 4 conductors.
What is the total cable length provided?
The total cable length provided is 76.20m.
What is the cable jacket color and material?
The cable jacket color is yellow and the insulation material is EP Rubber.
What is the outer jacket diameter of the cable?
The outer jacket diameter of the cable is 10.41mm.
What is the maximum current per contact for this cable?
The maximum current per contact for this cable is 8.0A.
What is the net weight of the cable?
The net weight of the cable is 53.977g.
