Woodhead 29T81 - Safeway® Connector with Locking Blade, 4 Pole/5 Wire, NEMA L21-30, 3ø 208V
Woodhead

29T81

Alternate Item Number: 1301450084

UPC: 786788706999

Documents & Media
Specification Sheet

Contact for Pricing

Overview

The Woodhead Safeway® Connector, SKU 29T81, is engineered for robust 3-phase 208V applications requiring secure connections. This 30A, 4-pole/5-wire connector features a NEMA L21-30 configuration and a locking blade design, ensuring tamper resistance and stability in high-vibration environments. Its NEo-TEX® Paracril OZO rubber housing provides exceptional resistance to abrasion, chemicals, and extreme temperatures, operating reliably from -40°C to 75°C. The floating blade construction ensures self-alignment for optimal mechanical and electrical contact, minimizing wear and heat generation. Wiring is simplified with color-coded, pre-set ¼" tri-drive terminal screws compatible with straight blade, Phillips, and square-drive screwdrivers. A transparent wiring guide allows for visual verification of wire placement before securing. The two-piece cord-clamp strain relief, also featuring tri-drive screws, firmly secures the cord. Constructed with nickel-plated brass blades and contacts, a nylon face insert, and a brass wire saddle clamp, this connector is built for longevity. Its Super-Safeway™ design offers superior resistance to corrosion, UV, and mechanical stress. UL File No. E10176 and CSA File No. LR6837 certified. Ideal for CNC machines, generators, data centers, oil & gas, and manufacturing facilities.
  • 30A, 4-Pole/5-Wire, NEMA L21-30 Configuration for 3-Phase 208V Systems
  • NEo-TEX® Paracril OZO Rubber Housing: Abrasion, Chemical, and Temperature Resistant (-40°C to 75°C)
  • Locking Blade Design for Tamper-Resistant, High-Vibration Applications
  • Floating Blade Construction for Self-Alignment and Enhanced Electrical/Mechanical Connection
  • Tri-Drive Terminals and Two-Piece Cord Clamp for Secure Wiring and Strain Relief

Specifications

Amperage Rating
30 A
Brand Name
Woodhead
Connection Type
Screw Terminal
Current Rating
30 A
Environmental Conditions
None
Material
NEo-TEX Paracril OZO rubber, Nickel-plated brass, Nylon
Nema Rating
NEMA L21-30
Number Of Poles
4-pole/5-wire
Number of Poles
4
Poles
4P/5W
Series
Safeway
Sub Brand
Safeway
Type
Connector
Voltage Rating
208 V
Voltage Rating
3Ø 208V
Package Weight (Imperial)
1.437 L
Package Weight (Metric)
0.652 kg
Safeway® Plug with Locking Blade, 4 Pole/5 Wire, NEMA L21-20, 3ø 208V, Yellow
