Woodhead 20052-1A - Super-Safeway® In-Line Industrial GFCI, Portable, Single Phase, Automatic Reset, NEMA 5-20 Plug, NEMA 5-20 Receptacle, Watertight, 20A, 120V, 0.61m (2.0') Cord Length
Woodhead

20052-1A

Alternate Item Number: 1301530123

UPC: 786788882464

Documents & Media
Technical DrawingSpecification Sheet

Contact for Pricing

Overview

The Woodhead Super-Safeway® In-Line Industrial GFCI (SKU: 20052-1A) offers robust ground fault protection for demanding industrial applications. This portable, single-phase unit features a 20A, 120V rating with a NEMA 5-20 plug and receptacle, ensuring compatibility with common industrial equipment. Its 0.61m (2.0') SJEOOW cord provides flexibility in placement. Engineered for harsh environments, the GFCI housing is constructed from impact-resistant nylon, complemented by stainless steel face screws and washers. It boasts a NEMA 4X enclosure rating for watertight protection against moisture and dust. A key feature is its automatic reset functionality, which restores power after a ground fault is cleared, minimizing downtime for equipment like lighting and HVAC. The unit includes a special filter to mitigate nuisance trips in electrically noisy environments, such as those with welding equipment or variable frequency drives. Woodhead's Super-Safeway® series is built for durability, with sealed internal strain relief to prevent cord pull-out. It is UL and cUL listed (File No.: E66308), meeting North American safety standards. For units manufactured after May 5, 2021, an IP69K enclosure rating is included, signifying resistance to high-pressure water jets and heavy-duty cleaning, making it suitable for washdown environments. Ideal for construction, mining, agriculture, and utilities, this portable GFCI safeguards personnel and equipment from electrical shock hazards. Its inline design simplifies installation between the power source and the load.
  • 20A, 120V Single Phase Operation
  • NEMA 5-20 Plug and Receptacle
  • 0.61m (2.0') SJEOOW Cord
  • Automatic Reset Functionality
  • NEMA 4X Watertight Enclosure Rating
  • UL and cUL listed for compliance with North American safety standards
  • IP69K-rated enclosure for resistance to water jets and harsh cleaning
  • Portable design for easy relocation between job sites or workstations
  • Stainless steel face screws and sealed strain relief for long-term durability
  • Ideal for construction, manufacturing, agriculture, and outdoor applications

Specifications

Brand Name
Woodhead
Connection Type
NEMA 5-20 Plug / NEMA 5-20 Receptacle
Current Rating
20 A
Enclosure
NEMA 4X
IP Rating
IP69K
Material
Nylon
Mounting
Portable
Mounting Type
Portable
Nema Rating
NEMA 5-20
Number Of Receptacles
1
Poles
2P+G
Receptacle
Single
Series
Super-Safeway®
Sub Brand
Super-Safeway
Type
GFCI Industrial Duty,Single Phase
Voltage Rating
120 V
