Westermo L110-F2G Managed Ethernet Switch
Alternate Item Number: 3643-0100
UPC: 100000000000
Documents & Media
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 8x 10/100 Mbit/s RJ-45 Ethernet ports
- 2x 100/1000 Mbit/s SFP slots for flexible uplinks
- Wide operating voltage range: 19-60 VDC
- Extended operating temperature: -40 to +70 °C
- 1x Digital I/O and 1x 2.5 mm console jack
- Operating temperature: -40 to +70 °C
- Backed by a 5-year warranty
- 5-year warranty
Specifications
Mounting Type | DIN Rail |
Series | L110 |
Voltage Rating | 24-48 VDC |
Voltage Rating | 19-60 VDC |
Package Weight (Imperial) | 1.87 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
CUSTOMDIN
DIN rail is a universal mounting option for electrical and industrial control products such as circuit breakers electrical supplies terminal blocks and more. The rail system is used to stabilize a wide variety of devices and products. Ordering pre-cut DIN rail helps increase productivity and decrease jobsite clutter. On-site Flexibility Streamline custom cuts DIN rail to any length so it is ready to use when it arrives on the jobsite. Additionally DIN rail can be easily removed if relocation is necessary. Features of Custom DIN Rail from Streamline - All cut DIN rail from Streamline is galvanized steel made to eliminate rusting. Streamline ensures that all custom DIN rail orders are: De-burred Custom Length Any quantity 1-1000+ Quick turnaround (typically 2 weeks or less from receipt of order) This mechanical support structure is a must for all electrical parts solutions big or small. DIN rail allows for mounting hardware easily and quickly. These durable and versatile rails make the perfect solution for all mounting applications. Save space time and money with these cost-effective mounting solutions. Order your custom cut DIN rail today!
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CPP24FMWBLY
The Mini-Com Flush Mount Modular Patch Panel accepts up to 24 Mini-Com Modules for unshielded applications in 1 RU, and mounts to 19 inch and 23 inch racks and cabinets. The panel mounts flush with the rack and can be identified with adhesive labels and is black.
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
UTP6AL1MBU
The TX6A™ 10Gig Cat 6A UTP Patch Cord is a 1-Meter, Blue cord constructed of 24 AWG, unshielded, twisted pair stranded, LSZH (60332-1) cable with high-performance modular plugs. Its MaTriX Tape Technology limits alien crosstalk, ensuring 10 Gb/s transmission. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
Frequently Asked Questions
What is the operating voltage range for the L110-F2G?
The L110-F2G operates on a rated voltage of 24 to 48 VDC with an operating range of 19 to 60 VDC.
Does the L110-F2G support VLANs?
Yes, the L110-F2G supports up to 64 VLANs for network segmentation and traffic management.
What is the operating temperature range?
The L110-F2G operates in temperatures from -40°C to +70°C (-40°F to +158°F).
Does the switch have galvanic isolation?
Yes, the L110-F2G features galvanic isolation to all ports for enhanced network protection.
What software does the L110-F2G use?
The L110-F2G runs Westermo's WeOS network operating system for management and configuration.
How to Install the Westermo L110-F2G
Step-by-step guide to mount and power the L110-F2G managed Ethernet switch.
Estimated time: 15m
Tools needed:
Phillips screwdriver
Supplies needed:
DIN rail, Mounting screws
- Mount the switch to DIN rail
Clip the L110-F2G onto a standard 35mm DIN rail. Ensure the switch is securely fastened.
- Connect power supply
Apply 24-48 VDC power to the terminal block. Verify the power LED illuminates.
- Connect Ethernet cables
Insert RJ-45 cables into the 10/100 Mbit/s ports. For fiber, install SFP modules in the Gigabit slots.
- Configure the switch
Use WeConfig software or the console port to configure VLANs, ports, and network settings.
